LPV-60-5 Meanwell 5V waterproof led driver

Specifications

LPV-60-5 Meanwell 5V waterproof led driver
1. Waterproof led driver
2. 2 year warranty
2. Suitable for LED lighting and Scree

LPV-60-5 Meanwell 5V waterproof led driver







LPV-60-5 Profile:



Meanwell LPV-60-5 is a 5V waterproof LED Driver, can use both inside and output side,  constant voltage output,  wide intput range,  high realibility.







Waterproof led driver Applications:



LED Strip Power Supply

LED Screen

LED lighting

Moving sign applications







Meanwell 5V LED Driver Warranty:   2 years







LPV-60-5 Meanwell power Features:



1.    Suitable for LED Ligiting and moving sign application

2.   Pass LPS

3.   Low cost, high reliability

4.   Class 2 power unit

5.  100% full load burn-in test

6.   Fully isolated plastic case

7.   Fully encapsulated with IP67 level





LPV60-5 Waterproof LED Driver Specification:





MODEL		LPV-60-5
OUTPUT	DC VOLTAGE	5V
	CURRENT RANGE	0 ~ 8A
	RATED CURRENT	8A
	RATED POWER	40W
	RIPPLE & NOISE (max.)  Note.2	80mVp-p
	VOLTAGE TOLERANCE  Note.3	±6.00%
	LINE REGULATION	±1.00%
	LOAD REGULATION	±6.00%
	SETUP, RISE TIME NOTE.6	500ms, 20ms / 230VAC 500ms, 20ms / 115VAC at full load
	HOLD UP TIME (Typ.)	50ms/230VAC 16ms/115VAC at full load
INPUT	VOLTAGE RANGE	90 ~ 264VAC 127 ~ 370VDC
	FREQUENCY RANGE	47 ~ 63Hz
	EFFICIENCY (Typ.)	76%
PROTECTION	OVER CURRENT	110 ~ 150% rated output power
		Protection type : Hiccup mode, recovers automatically after fault condition is removed
	OVER VOLTAGE	5.75 ~ 6.75V
		Protection type : Shut down O/P Voltage,re-power on to recover
ENVIRONMENT	WORKING TEMP.	-30 ~ +70°C (Refer to output load derating curve)
	WORKING HUMIDITY	20 ~ 90% RH non-condensing
	STORAGE TEMP., HUMIDITY	-40 ~ +80°C , 10 ~ 95% RH
	TEMP. COEFFICIENT	± 0.03%/°C (0 ~ 50°C )
	VIBRATION	10 ~ 500Hz, 2G 12min./1cycle, period for? 60min. each along X, Y, Z axes
SAFETY &EMC(Note 4)	SAFETY STANDARDS	UL879(except for LPV-60-5), UL1310(except for LPV-60-5), CSA C22.2 No. 207-M89(except for LPV-60-5, LPV-60-48), CAN/CSA C22.2 No. 223-M91(except for LPV-60-5,LPV-60-48), IP67 approved ; design refer to TUV EN60950-1
	WITHSTAND VOLTAGE?	I/P-O/P:3KVAC
	ISOLATION RESISTANCE	I/P-O/P:>100M Ohms /500VDC/ 25°C/70% RH
	EMI CONDUCTION & RADIATION	Compliance to EN55022 (CISPR22) Class B
	HARMONIC CURRENT	Compliance to EN61000-3-2 Class A,EN61000-3-3
	EMS	Compliance to EN61000-4-2,3,4,5,6,8,11; ENV50204, EN55024, light industry level, criteria A
	IMMUNITY
OTHERS	MTBF	732Khrs min. MIL-HDBK-217F (25 )
	DIMENSION	162.5*42.5*32mm (L*W*H)
	PACKING	0.4Kg; 32pcs/13.8Kg/0.56CUFT





LPV-60-5 Order Information:





LPV-60-5 Meanwell 5V waterproof led driver
