AC Hydraulic Forklifts Battery Semi Electric Pallet Jack

AC Hydraulic Forklifts Battery Semi Electric Pallet Jack photo-1
AC Hydraulic Forklifts Battery Semi Electric Pallet Jack photo-2
AC Hydraulic Forklifts Battery Semi Electric Pallet Jack photo-3
AC Hydraulic Forklifts Battery Semi Electric Pallet Jack photo-4
AC Hydraulic Forklifts Battery Semi Electric Pallet Jack photo-5
AC Hydraulic Forklifts Battery Semi Electric Pallet Jack photo-6
US$ 800 - 1,200 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
HOCEN
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Jiangsu, China
Brand Name HOCEN
Model Number C20HC
Type Other, semi-electric
Power Souce Other, electric
Rated Loading Capacity 2500kg
Max. Lifting Height 205mm
Min. Lifting Height 680mm
Fork Length 1150mm
Fork Width 520/680mm
Overall Dimensions 1785x680x1310mm
Certification CE
After-sales Service Provided Engineers available to service machinery overseas



  AC Hydraulic Forklifts battery semi electric pallet jack







Product Description

AC Hydraulic Forklifts battery semi electric pallet jack



Our electric pallet truck is an economic walkie-electric/semi electric pallet truck, with rated capacity 2000kgs.



1. Manual lifting, power traveling

2. High-strength frame design, suitable for tough workplaces, ensures longer service life

3. Configure with 210Ah large capacity battery, can keep work more than 12 hours

4. Reliable and safe brake, flexible operation and steady starting

5. 3-gear resistance speed adjustment, can choose to install poleless speed adjustment





Features&Parameters



AC Hydraulic Forklifts battery semi electric pallet jack







Identification

Model



CBD20 Semi Auto Electric hand pallet truck

Config-code

resistance speed adjustment



C20

C25

poleless speed adjustment



CW20

CW25

Drive Unit



Semi-electric

Operation type



Pedestrian

Load capacity

kg

2000

2500

Dimension

Overall length

mm

1800

Overall width

mm

730

Overall height

mm

1310

Min. fork height

mm

85

Max. fork height

mm

205

Fork dimensions

mm

1150x160x60

Maximum fork width

mm

520 / 680

Turning radius

mm

1610

Wheelbase

mm

1405

Performance

Travel speed

loaded

Km/h

5.0

5.0

unloaded

Km/h

9.1

Brake type



Electric-magnetic

Electric Motor

Drive motor power

KW

0.75

Battery

Ah/V

210/24

210/24

Weight

Weight w/o battery

kg

275

287

Battery weight

kg

185

185





Pictures & Details



AC Hydraulic Forklifts battery semi electric pallet jack



AC Hydraulic Forklifts battery semi electric pallet jackAC Hydraulic Forklifts battery semi electric pallet jack







AC Hydraulic Forklifts battery semi electric pallet jack



 AC Hydraulic Forklifts battery semi electric pallet jack

Workshop show

AC Hydraulic Forklifts battery semi electric pallet jack



AC Hydraulic Forklifts battery semi electric pallet jack

FAQ

AC Hydraulic Forklifts battery semi electric pallet jack



Q:Why choose Suzhou Haocheng Logistics Machinery Co.,LTD?
A:Because we are professional Manufacturer which has more than 16years OEM experience, most parts of products produced by ourselves.E.g. Pump and cylinder are produced by high-technology CNC machine;welding do use the aoto welding robot machine.

Q:What about the quality of the products?
A:We have five inspectionsteps during the production.
1th, inspect material according to ISO 2859
2th, 100% inspection in production process
3th, 100% inspection when assembling finished(Load Limiting Device Test and Proof Load Test)
4th, inspect products before shipment according to ISO 2859
5th, inspection by buyer (if need)
Note: We will ensure that 100% qualified before shipment

Q:What's the leadtime?
A:Nomally 45 days.
If you book more than 5 items mixed in one container, it will be 60 days.
If you book one item in one container, it will be 30 days.

Q:What about the guarantee?
A:One year after shipment.
If the problem coursed by factory side, we will supply free spare parts or products untill the problem solved.
If the problem coursed by customer, We will supply technic support and supply spare parts with lower price.

Q:Why your price is a little higher than other factory or trading company?
A:Because we would like to follow a win-win stratery so that we can have a long business relationship,which is good and important for both of us.
So we do not sell light weight products or sticker high capacity(like 5 ton sticker 10 ton)
We ensure that every products from Tongli are goods genuine and prices reasonable.

Q:How to contact us?
A:Workday(8:00 - 17:00), feed-back in 24 hours
