Product features
1,The product`s lifting system is made of light-weight & high-strength aluminum alloy
2,The motor is powered by AC/DC power/Charged battery/diesel engine.
3,Remote control is available to equip according to customer`s request.
4,This product is easily equiped with other vehicles or stationary device such as mobile trailers,trucks and brackets.
5,Up to 20m(65ft.) max. Lift height (4 lift pillars)/1.5*1m(4.9*3.3ft) platform area/200kg(441lb.) rated capacity.
| Model | Lifting height | Loading Capacity | Table Size | Overall Dimension | Weight | Power | Voltage |
| single mast | |||||||
| SJYL0.1-6 | 6m | 100kg | 600*600mm | 1250*840*1850mm | 400kg | 1.1kw | 220v |
| SJYL0.1-8 | 8m | 100kg | 600*600mm | 1350*840*1950mm | 450kg | 1.1kw | 220v |
| SJYL0.1-10 | 10m | 100kg | 600*600mm | 1500*840*2300mm | 500kg | 1.5kw | 220v |
| double masts | |||||||
| SJYL0.2-6 | 6m | 200kg | 1200*600mm | 1200*840*1980mm | 500kg | 1.5kw | 220v |
| SJYL0.2-8 | 8m | 200kg | 1400*600mm | 1400*840*1980mm | 600kg | 1.5kw | 220v |
| SJYL0.2-10 | 10m | 200kg | 1500*600mm | 1550*840*1980mm | 680kg | 1.5kw | 220v |
| SJYL0.2-12 | 12m | 200kg | 1550*600mm | 1950*960*1980mm | 750kg | 1.5kw | 220v |
| SJYL0.2-14 | 14m | 200kg | 1550*600mm | 1950*960*2300mm | 800kg | 1.5kw | 220v |
| SJYL0.2-16 | 16m | 200kg | 1550*600mm | 2000*1020*2900mm | 960kg | 1.5kw | 220v |
| three masts | |||||||
| SJYL0.2-14 | 14m | 200kg | 1550*950mm | 1950*1200*2400mm | 2.2kw | 220v | |
| SJYL0.2-16 | 16m | 200kg | 1550*950mm | 2000*1200*2900mm | 2.2kw | 220v | |
| four masts | |||||||
| SJYL0.2-14 | 14m | 200kg | 1550*950mm | 1950*1200*2400mm | 2.2kw | 220v | |
| SJYL0.2-16 | 16m | 200kg | 1550*1150mm | 2000*1400*2900mm | 2.2kw | 220v | |
| SJYL0.2-18 | 18m | 200kg | 1650*1150mm | 2200*1400*2900mm | 2.2kw | 220v | |
| SJYL0.2-20 | 20m | 200kg | 1650*1150mm | 2200*1400*2900mm | 2.2kw | 220v |
Truewin believes quality maketh faith,and faith is the only reason why Truewin can stand on the top of hydraulic equipments
Truewinners insist that quality is based on every little step,so all parts are purchased from certified parts suppliers such as Bosch,Fengfan,Fujikon.etc.
Best parts together,Best product is here.
Yes,True win!
Maintenance
A. Daily or refueling: Check the parts are good or bad Check hydraulic oil level and colour
B. Every 250hours or 3months: Change lubricating oil Check cylinders
C. Every 500hours or 6 months: Check tubes, pipes and value
D. Every 1000 hours or 1 year: Change hydraulic oil Grease rotation bearing and wear pads
E. Every 2000 hours or 2 years:Check hydraulic tank, lid and vent
F. Note: Maintain the chassis according to the Chassis’ Service manual
Shandong Truewin Construction Materials Co.,.Ltd is a modern manufacturer complex focusing on industrial hydraulic equipment & device.With 20 years experience of hydraulic quipment design and produce,Truewin has developed 42 sub models from 13 parent product lines with 3,000 productive capacity per month and growing more,11000 m² factory plant with complete production lines to guarantee all the products can be delivered to the client`s hand in time.leading the whole manufacturing industry in Shandong.Though being one of the best producers among China,Truewin never slow down to explorer farther and greater.
Yes,True win!
FAQ
Q:What are you? Trade Company or manufacturer?
A: We are both manufacturer & tradding company.
Q:What’s the advantage of your company?
A:We`re experienced manufacturer and overseas dealer,Our products have been exported to over 100 countries.An independent research team specially focusing on machinary design and production. A service team for customers will provide feedback within 24 hours.Products built with Germany and Italian technology on assembly line.
Q:Can I customise the product according to my own willing?
A:Yes,we are high quality OEM/ODM manufacturer,we can satisfy all the requests to the product.
Q:What need you know when i inquiry to you ?
A: We need to know your Max Capacity,Platform size and Lift height.
Q:What’s the Min order to your company?
A:At least 1 set of the product.,and the product you ordered will be sent in a week as long as inventory is available
Q: When the product can be delivered?
A: Commonly the lead time will be within 15 days after payment.
