singal mast Personnel Lifts
DESCRIPTION
This man lift offer a safe, quick and easy method of reaching overhead areas. Mostly designed to lift one person, these platforms are extremely compact, lightweight and easy to maneuver.
The vertical personnel lift consists of a working platform attached to an aluminium mast that extends vertically, which in turn is mounted on a steel base. These personnel lifts has a reach of up to 8m and capacities up to 120kg
Application
All maintenance work, Factory fit outs in tight areas. Ideal warehouse use between racking and narrow aisle areas.Hospitals, Schools, Offices for suspended ceiling maintenance.
Level adjustment before lift working:
Stabilizer for precise leveling
Specifications:
Model |
TWA6-1 |
TWA8-1 |
TWA10-1 |
|||
Max. Platform Height |
mm |
6000 |
8000 |
10000 |
||
Max. Machine Height |
7350 |
9460 |
11300 |
|||
Min. Platform Height |
580 |
|||||
Ground Clearance |
60 |
|||||
Lift Rated Capacity |
kg |
150 |
125 |
|||
Platform Size |
mm |
630*650 |
||||
Outspread Size |
2030*1840 |
|||||
Electrical Source |
AC |
v |
220-240 |
|||
DC |
12 |
|||||
Aneroid Battery |
v/Ah |
2*12/75 |
||||
Charger |
v/A |
12/15 |
||||
Lifting Motor |
AC |
v/kw |
220/0.75-1.5 |
|||
DC |
12/2.5 |
|||||
Overall Length |
mm |
1420 |
||||
Overall Width |
840 |
|||||
Overall Height |
1920 |
2980 |
||||
Overall |
AC |
kg |
410 |
450 |
490 |
|
DC |
450 |
480 |
525 |
|||
