Aluminium self-propelled aerial work platform
Aerial lift platform description:
4)It has unique upper platform and lower platform design.
Aerial lift platform advantage:
Application: persons working high above the ground.
Maximum platform height available: Optional: 4-20m.
Power supply available: single phase AC power.
Walking forms available: save manpower.
Optional: self-propelled.
| Model Number | Max height(m) | Max working height(m) | Rate load(kg) | Platform size (m) | Power supply | Power | weigth (kg) | Overall Dimensions (L*W*H)(m) | |
| V/HZ | (KW) | ||||||||
| Single mast lift platform | GTWY4-100 | 4 | 5.7 | 125 | 0.51*0.55 | AC220/50HZ | 1.1 | 250 | 1.2*0.78*1.65 |
| GTWY6-100 | 6 | 7.8 | 125 | 0.58*0.64 | AC220/50HZ | 1.1 | 280 | 1.2*0.78*1.65 | |
| GTWY8-100 | 8 | 9.7 | 125 | 0.58*0.64 | AC220/50HZ | 1.1 | 300 | 1.3*0.85*2.02 | |
| GTWY9-100 | 9 | 10.7 | 125 | 0.58*0.64 | AC220/50HZ | 1.1 | 320 | 1.3*0.85*2.02 | |
| Double mast lift platform | GTWY6-200s | 6 | 7.7 | 200 | 1.16*0.54 | AC220/50HZ | 1.1 | 320 | 1.45*0.82*1.65 |
| GTWY8-200s | 8 | 9.7 | 200 | 1.26*0.54 | AC220/50HZ | 1.1 | 380 | 1.45*0.82*1.8 | |
| GTWY9-200s | 9 | 10.7 | 200 | 1.36*0.54 | AC220/50HZ | 1.1 | 450 | 1.55*0.9*2 | |
| GTWY10-200s | 10 | 11.7 | 200 | 1.36*0.54 | AC220/50HZ | 1.1 | 490 | 1.55*0.9*2 | |
| GTWY12-200s | 12 | 13.7 | 200 | 1.46*0.54 | AC220/50HZ | 1.5 | 560 | 1.65*0.9*2 | |
| Self-propelled lift platform (Single mast) | GTWY4-100 | 4 | 5.7 | 125 | 0.51*0.55 | AC220/50HZ | 0.75 | 185 | 1.05*0.88*1.70 |
| GTWY6-100 | 6 | 7.7 | 125 | 0.65*0.61 | AC220/50HZ | 0.75 | 210 | 1.20*0.88*1.70 | |
| GTWY8-100 | 8 | 9.7 | 125 | 0.65*0.61 | AC220/50HZ | 0.75 | 220 | 1.20*0.88*1.98 | |
| Self-propelled lift platform (Double mast) | GTWY6-200S | 6 | 7.7 | 200 | 1.36*0.61 | AC220/50HZ | 1.5 | 320 | 1.48*0.9*2.06 |
| GTWY7-200S | 7 | 8.7 | 200 | 1.36*0.60 | AC220/50HZ | 1.5 | 335 | 1.48*0.9*2.06 | |
| GTWY8-200S | 8 | 9.7 | 200 | 1.36*0.60 | AC220/50HZ | 1.5 | 385 | 1.48*0.9*2.06 | |
| GTWY9-200S | 9 | 10.7 | 200 | 1.36*0.60 | AC220/50HZ | 1.5 | 450 | 1.48*0.9*2.06 | |
| GTWY10-200S | 10 | 11.7 | 200 | 1.36*0.60 | AC220/50HZ | 1.5 | 490 | 1.48*0.9*2.06 | |
| GTWY12-200S | 12 | 13.7 | 200 | 1.46*0.60 | AC220/50HZ | 1.5 | 560 | 1.58*0.9*2.06 | |
| Self-propelled lift platform (Three mast) | GTWY13-250S | 13 | 14.7 | 250 | 1.56*0.80 | AC220/50HZ | 1.5 | 920 | 1.69*1.13*2.48 |
| GTWY14-250S | 14 | 15.7 | 250 | 1.56*0.80 | AC220/50HZ | 1.5 | 980 | 1.69*1.13*2.48 | |
Safety configuration:
1.Level gauge on chassic
2.Emergency manual descending switch
3.Antiwear polyurethane tire
4.Limit switch
5.Over load protection
6.Rubber Oil pipe:double deck steer wire
Our cetificate:
OUR COMPANY INFORMATION
ABOUT US
Established in 2008, Suzhou Haocheng Logistics machinery is a professional manufacturer and exporter that is concerned with the design, development and production of logistics equipments . We are located in Suzhou City. Jiangsu province. China , with convenient transportation .....
OUR ADVANTAGE
We have over 48 employees, an annual sales figure that exceeds USD 8 million and are currently exporting 25% of our production worldwide. Our well-equipped facilities and excellent quality control throughout all stages of production enables us to guarantee total customer satisfaction.
OUR HONOR
As a result of our high quality products and outstanding customer service, we have gained a global sales network reaching South Korea, American ,Thailand. If you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are looking ....
OUR CUSTOMER AND EXHIBITION:
Hao Cheng service:
1. We supply ONE-STOP-SHOP solution service for logistics equipment.
2. We supply one year warranty and continuous parts supply
3. Company located in Suzhou,We also supply the ONE-STOP-SHOP logistics service for export business,Our nearest export port is Shanghai.
Model Of Packing:
Method:Pallet,Wooden Case or Nude Packing...
FAQ:
We accept make to order,so pls tell me more detail about:
1.Max rate load(kg)
2.Max height (mm)
3.Table size (L*W)
4.Power and voltage
