Single Color Offset Numbering Printing Machine With Perforation

Single Color Offset Numbering Printing Machine With Perforation thumbnail-1
Single Color Offset Numbering Printing Machine With Perforation thumbnail-2
Single Color Offset Numbering Printing Machine With Perforation thumbnail-3
Single Color Offset Numbering Printing Machine With Perforation thumbnail-4
Single Color Offset Numbering Printing Machine With Perforation photo-1
Single Color Offset Numbering Printing Machine With Perforation photo-2
Single Color Offset Numbering Printing Machine With Perforation photo-3
Single Color Offset Numbering Printing Machine With Perforation photo-4
US$ 4,000 - 5,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Flatbed Printer
Place of Origin:
Jiangsu, China
Contact Supplier Request Quote Chat Now
Suzhou Ruicai Electron Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Plate Type Flatbed Printer
Place of Origin Jiangsu, China
Brand Name Ruicai
Model Number 56IINP
Usage Paper Printer
Automatic Grade Automatic
Voltage 220V/50Hz
Gross Power 1.3kw
Dimensions(L*W*H) 2089*1060*1340mm
Weight 930kgs
Certification ISO9001 CE
After-sales Service Provided Overseas service center available

Single Color Offset Numbering Printing Machine with Perforation 56IINP



Single Color Offset Numbering Printing Machine with Perforation



Product Description

Single Color Offset Numbering Printing Machine with Perforation



Model

56IINP

Max Printing Area

540*380mm

Max Paper Size

560*395mm

Blanket Size

560*455*1.95mm

Paper Type

28-250g

Ink Roller

Main system 14pcs(3 form ink rollers),NP system 6pcs(2 form ink rollers)

Dampening Rollers

4 pcs (1 form dampening roller)

Registering mechanism

 Roller type side lay

Plate Size

560*455*0.15mm

Printing Speed

2000-9000pcs/hr

Numbering device

Straight type (horizontal): 63 heads Max.

(9 heads on a ring × 7 rings on a shaft)

Convex type (vertical): 56 heads Max.

(7 heads on a ring × 8 rings on a shaft)

Letter press printing device

Cylinder type: 90 × 345mm Max.

Mounting ring type: 30 × 40mm Max.

Perforating device

Cross perforation: Min 25mm

Vertical perforation: 5mm(blade-perfo type)

Main Motor

0.75kw

Air Pump Motor

0.55kw

Machine Size

2089*1060*1340mm

Machine Weight

930kgs



Single Color Offset Numbering Printing Machine with Perforation



56IINP single color offset printing machine with number printing



1) Single color offset printer for sale

2) Equipped with multi-purpose NP system
3) Suitable for resin relief plate printing available
4) Ink applicator for number printing adopts open-close type, which can be opened and closed within an angle of 120 degrees
5) Two ink form rollers in NP system enable to get enough ink for relief printing and color printing
6) Line-pressing device can simultaneously press both column and lateral lines
7) Lines are precisely pressed in the right location

8) Double sheets detection:It can avoid the problem such as double sheets,paper overlap and non-stop.

9) Exact registration:Front paper stopper of registration, both side-pulled-paper stopper, paper feeding horizontal registration, paper feeding table slight adjustment,plate cylinder registration of up/down.

10) Preset counter:This machine adopts electromagnetic preset counter. If the quantized printing work finishes, the paper feeding stops automatically.

11) Double sheets detection:It can avoid the problem such as double sheets,paper overlap and non-stop.

12) The whole machine is controlled by PLC. There are functions such as auto press, auto stop while paper jam, powder jet, steps running forward and backward.





Single Color Offset Numbering Printing Machine with Perforation



Single Color Offset Numbering Printing Machine with Perforation



Our Services

Single Color Offset Numbering Printing Machine with Perforation





1. Ruicai Provide 20 months warranty for all customers.

2. During warranty, we provide free normal spare parts once machine has probem.

3. Ruicai will solve customer's machine problem within 24 hours from the time problem raised.

4. Ruicai has enough spare parts for machines.

5. When machine out of warranty, Ruicai still provide free technical support and spare parts charged to customers.





Single Color Offset Numbering Printing Machine with Perforation

Single Color Offset Numbering Printing Machine with Perforation

Ruicai Group found in 1995, we have 20 years of experience in the field of Printing and Finishing Equipment. Our products include paper cutting machine, creasing machine, perfect binding machine, roll laminator, creasing machine, post-press machines, graphic machines, office machines and so on. We can provide one-stop solution to our customers. In 2004, the products got CE proved and gradually came to Canada and European countries. In 2006, got ISO9000 proved. Now our products cover all mature and emerging markets. We have around 200 dealers all over the world.

We have an experienced R&D team, a hardworking production team, an excellent sales team and a perfect after sales team with high quality management system. We are keen on developing and innovating new products to meet different markets’ need. Every year, there are several new machines being put on market. We believe through our efforts, we and our partners from all over the world will have a fantastic cooperation and great future together!

Our faith is "Honesty based quality first and service oriented". Ruicai Expect a long term cooperation with all customers, not one time business.
