TES-1303 Dual Input K Type Thermometer

Measuring Range

-50°C -1300 °C ; -50 °F  -1999 °F

Sensor

K Type thermocouple

Input

Single(1300), Dual(1303)

Resolution

-50°C + 199.9°C...0.1°C
-50°F  + 199.9°F ...0.1°F
(Others-1°C/1°F )

Accuracy

-50 °C to 199.9 °C ...0.3% rdg + 1 °C
-50 °F  to 199.9 °F ...0.3% rdg + 2 °F
-50 °C to 1000 °C ...0.5% rdg + 1 °C
-50 °F  to 1999 °F F. ..0.5% rdg + 2 °F
1000 °C to 1300 °C ..0.75% rdg + 1 °C
(apply to mainframe only at 23 °C +/- 5 °C)

Function

H Data Hold & Display °C / o F selection
0.1 o /1 o resolution selection
T1 & T2 dual points display
T1 - T2 differential measurement
3-1/2 digit LCD

Temperature Coefficient

Less than 0.1 time the applicable
accuracy specification per °C (°F )

Overrange

1------

Low Battery

BT

Temperature Coefficient

Less than 0.1 time the applicable
accuracy specification per °C (°F )

Input Protection

60V DC or 24 Vrms AC maximum
input voltage on any combination of
input Connector.
Sampling Rate: 2.5 times/sec.

Operating Condition

0 °C - 50 °C (32 °F -122 °F ),
0-90% R.H. (0-35 °C )

Power Source

one 9V battery

Size Weight

135mm(L)x72mm(W)x31mm(H) & 57g
Accessories: Battery & Instruction Manual

* OPTIONAL TEMPERATURE PROBES

Model Range (Type K (CA)THERMOCOUPLE)
TP-K01 Bead -50 °C to 200 °C /-58 °F  to 392 °F
General Purpose
TP-K02 Immersion -50 °C to 1000 °C /-58°F  to 1832 °F
Liquid or gels.
TP-K03 Surface -50 °C to 750 °C /-58°F  to 1382 °F
