TES-1315 K/J/E/T/R/S/N Data-Logger Thermometer With USB

Measuring Range

K - Type : -200°C to +1372°C (-328°F  to +2501°F )
J - Type : -210°C to +1200°C (-346°F  to +2192°F )
E - Type : -150°C to +1000°C (-238°F  to +1832°F )
T - Type : -250°C to +400°C (-418°F  to +752°F )
R and S - Type : 0°C to +1767°C (+32°F  to +3212°F )
N - Type : -200°C to +1300°C (-328°F  to +2372°F )

Display Resolution

0.1°C / °F  / K < 2000°
1.0°C / °F  / K </=2000°

Measurement Accuracy
(According to ITS-90)

K, J, E, T, and N-Type : ± [0.05% of reading +0.3°C (0.6°F )]
[below -100°C (-148°F ) : add 0.15 % of reading for K-, J-, E-, and N-Type ; and 0.45% of reading for T-Type]
R-and S-Type : ± [0.05% of reading + 0.4°C (0.8°F )]

Temperature Coefficient

0.01% of reading + 0.03°C per °C (0.05 °F  per °F ) outside the specified +18°C to 28°C (+64°F  to +82°F ) range
[LCD ranging : below -100°C (-148°F ) : add 0.04% of reading for K-, J-, E, and N- Type; and 0.08% of reading for T- Type]

Maximum Differential
Common Mode Voltage

1V (Maximum voltage difference between T1 and T2)

Input Protection

30V maximum input voltage on any
Combination of input Connector

Sampling Rate

1 time/sec

Operating/Storage Conditions

0°C ~ 40°C < 80% RH ,
-10°C ~ 60°C < 70%RH

Power Source

6 pcs size AAA Battery

Battery Life

Approx. 300hours. (not including backlight and beeper)

Size

152(L) ×72(W) ×37(H)mm

Weight

Approx. 300g

Accessories

1. Instruction manual, Battery
2. Software for WINDOWS, USB Cable, TP-K01*1pc
