156-164MHz VHF Marine Mobile Radio Transceiver RS-507M

156-164MHz VHF Marine Mobile Radio Transceiver RS-507M thumbnail-1
156-164MHz VHF Marine Mobile Radio Transceiver RS-507M thumbnail-2
156-164MHz VHF Marine Mobile Radio Transceiver RS-507M thumbnail-3
156-164MHz VHF Marine Mobile Radio Transceiver RS-507M thumbnail-4
156-164MHz VHF Marine Mobile Radio Transceiver RS-507M photo-1
156-164MHz VHF Marine Mobile Radio Transceiver RS-507M photo-2
156-164MHz VHF Marine Mobile Radio Transceiver RS-507M photo-3
156-164MHz VHF Marine Mobile Radio Transceiver RS-507M photo-4
US$ 119.9 - 145.9 MOQ: 1 Piece
Key Specifications
Get Latest Price
Type:
Vehicle Mouted
Dimensions:
145*50*190mm
Frequency Range:
TX:156.025-157.425MHz/RX:156.050-163.275MHz
Contact Supplier Request Quote Chat Now
Zhengzhou EShow Import And Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen HongKong Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Vehicle Mouted
Dimensions 145*50*190mm
Frequency Range TX:156.025-157.425MHz/RX:156.050-163.275MHz
Storage Channel 88CH

156-164MHz VHF Marine mobile Radio transceiver RS-507M





156-164MHz VHF Marine mobile Radio transceiver RS-507M

 156-164MHz VHF Marine mobile Radio transceiver RS-507M156-164MHz VHF Marine mobile Radio transceiver RS-507M156-164MHz VHF Marine mobile Radio transceiver RS-507M156-164MHz VHF Marine mobile Radio transceiver RS-507M



156-164MHz VHF Marine mobile Radio transceiver RS-507M

Feature:

  1. 100% Brand New & Never Used
  2. Dual-watch and Tri-watch Functions
  3. Built-In DSC
  4. Favorite Channel Function
  5. Aqua quake Draining Function
  6. 10 Weather Channels and Weather Alert
  7. Large-screen display and easy to operate
  8. IP67 waterproof (depth of 1 meter and can prevent flooding 30 minutes)
  9. External GPS Receiver Function
  10. DSC Call Auto-answer Function
  11. Scan Resume Timer

Specification:

General

Frequency Range

TX:156.025-157.425MHz

RX:156.050-163.275MHz

Channel No.

88 channels

Modulation mode

FM(16K0G3E),DSC(16K0G2B)

Frequency Stability

±10ppm

Work Voltage

DC13.8V (±15%)

Operating Temperature

-20°C~+60°C

Antenna Impedance

50ohm

Dimensions

153x67x152mm

Weight

742g

Transmitter

RF Power Output

25W/1W

Maximum Frequency Deviation

±5KHz

Spurious and Harmonic

<= -70dB(H)

<= -56dB(L)

Adjacent Channel Selectivity

>=70dB

TX Audio Distortion

<= 10%

Current Consumption

<= 5.5A(High power)

<= 1.5A(Low power)

Input Impedance

2Kohm(Microphone)

Receiver

RX Sensitivity

<= 0.2µV

Squelch Sensitivity

±5KHz

Adjacent Channel Selectivity

>=70dB

Intermodulation Anti-interference

>=70dB

Spurious Response Rejection

>=70dB



156-164MHz VHF Marine mobile Radio transceiver RS-507M

l 1x Mobile transceiver

l 1x DC Power Cable

l 1x Bracket

l 1X Bracket Screw

l 1x User’s Manual
