Wholesale Milky quartz price for heating usage

Name: Wholesale Milky quartz price for heating usage
Brand: Liaison Quartz
Availability: InStock

FOB Price

USD $0.5 - $10 / Piece

100 Pieces(Min.Order)

Supply Ability 2000000 Piece / Pieces per Month
Port Tsingtao Shanghai Lianyungang
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China	Brand Name	Liaison Quartz
Model Number	NA	Type	Translucent Quartz Pipe
Color	Milky	Application	Laboratory Instrument
Surface Treatment	Grinded	Shape	One End Closed Quartz Tube
Outside Diameter	3-300mm	Ozone Content	High Ozone

Packaging Details

Bubble bag>Carton Box>Wooden case, Liaisonquartz standard packing for Wholesale Milky quartz price for heating usage

Product Description

Wholesale Milky quartz price for heating usage

Product Description

Physical properties
SiO2 :	99.99%
Density :	2.2(g/cm3)
Degree of hardness mosh' scale :	6.6
Coefficient of expansion 25--300℃ ℃-1 ( ×10-6 )	0.58
Melting point:	1732°C
Working temperature :	Under 1100°C
Max temperature can reach in a short time :	1450°C
Acid tolerance:	30 times than Ceramics , 150 times than Stainless steel
Visible light transmittance :	above 93%
UV spectral region transmittance:	80%
Resistance value :	10000 times than ordinary glass
Annealing point:	1180°C
softening point:	1630°C
Strain point:	1100°C

Dimension Tolerance(mm)
Designation	OD	WT	Max. Siding	Max. Ovality	Max. Bow
1-3mm	±0.05	±0.05	0.05	0.05	1‰
3-10mm	±0.1	±0.1	0.1	0.15	2‰
10-20mm	±0.2	±0.1	0.1	0.2	2‰
20-30	±0.2	±0.15	0.15	0.2	2‰
30-40	±0.4	±0.15	0.2	0.2	2‰
40-50	±0.5	±0.2	0.25	0.25	2‰
50-65	±0.6	±0.2	0.35	0.25	2.5‰
65-85	±0.8	±0.3	0.45	0.3	2.5‰
85-100	±1	±0.3	0.5	0.5	2.5‰
100-150	±1.5	±0.4	0.5	0.8	3‰
150-200	±2	±0.6	0.6	1	4‰
200-300	±3	±0.8	0.7	2	5‰

Spectral Transmission at 1.0mm Thickness
nm	220	255	280	315	350	380	590	780
%	89	91	93	93	93	93	93.2	93.4

Chemical Composition, unit: PPM
K+Na	Ca	Fe	Al	Mg	Ti	Ba	Li	Cu
<10	<3	<1.5	<20	<1.0	<3.0	<0.2	<1.0	<0.5

Application of standard clear quartz tube: halogen lamp, mercury lamp, single end lamp,automobile lamp,stage lamp, The thermoelectric boiler, The photocopier lamp, Water treatment lamp casing,quartz ware and pipe.

Application of Ultraviolet quartz tube : Single-ended metal halide lamp,automobile metal halide lamp,G12 metal halide lamp, anti-explosion metal halide lamp, High power stage light and so on.

Application of free ozone quartz tube : Kill germs free ozone light,the material of hospital ,family,and public place Ultraviolet kill germs,and water treatment.

Application of quartz rod : Linear light source products, light guide stick, light pipe, Fiber Lighting, Quartz fiber manufacturing,semiconductor silicon wafer, hollow half round.

Application of film coated quartz heater tube: Instant Hot water heater, Alkaline water purifier, Electrothermal heater, Oven heating, Aquarium heater,Screen Printing, Drying, Sealing, Food Warming, Plastic Forming, Laminating.

Application of quartz plate: military industrial complex, machinery, metallurgy, printing and dyeing, optical instruments, high temperature sight glasses, firehole industries such as high temperature and other industries, electric light source equipment, Labortory instrument, chemical apparatus.

Production Flow

General process of quartz tube :End closing-Cutting-Fire polished-Cleaning-Dring-Annealing-Cooling down-Inspecting-Packing

Company Profile

Lianyungang Liaison Quartz Co., Ltd.

Lianyungang Liaison Quartz Co., Ltd. covers an area of more than 8,000 square meters, with a building area of 4,000 square meters. We have nearly 50 existing engineering and technical personnel, with an annual output of nearly 500 tons of high-quality quartz glass tubes. Our main products are transparent quartz glass tube, creamy white quartz glass tube, low-quartz glass tube, filter UV quartz glass tube and ozone quartz glass tube. We sell our products to clients in the United States, the UK, Japan, South Korea and more than 30 domestic and overseas manufacturers. Our company follows the tenet of "quality first, supremacy of users" and adheres to the aim of "integrity, efficient innovation and pragmatism". We adhere to the policy of "technical innovation". We pay attention to product quality and after-sales service. We welcome friends from at home and abroad to seek common development. Our company is located in Donghai County in Jiangsu Province. With highways, railways, and civil aviation and maritime networks, the transportation is extremely convenient. We set up a company in 2005 to import advanced quartz tube processing equipment, including quartz tube cutting, mouth and back burning, and flanging equipment. Our facilities are widely used in disinfection product, aquatic light, and heater production. We warmly welcome clients' presence in all sectors.
