Milky quartz tube for heating application used in chemical field

Name: Milky quartz tube for heating application used in chemical field
Brand: Liaison Quartz
Availability: InStock

FOB Price

USD $0.5 - $8 / Piece

100 Pieces(Min.Order)

Supply Ability 200000 Piece / Pieces per Month
Port Tstingtao Shanghai Lianyungang
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China	Brand Name	Liaison Quartz
Model Number	N/A	Type	Opaque Quartz Pipe
Color	Milky	Application	Heating
Surface Treatment	Grinded
Outside Diameter	3-300mm	Ozone Content	High Ozone

Packaging Details

bubble bag>carton box>wooden case

Product Description

Milky quartz tube for heating application used in chemical field

General Characters

-High purity, SiO2>99.9%

-High temperature resistance

-Anti-corrosion

-Electrical insulation

-High spectral transmission >90%

-High temperature stability

Physical properties
SiO2 :	99.9%
Density :	2.2(g/cm3)
Degree of hardness mosh' scale :	6.6
Coefficient of expansion 25--300℃ ℃-1 ( ×10-6 )	0.58
Melting point:	1732°C
Working temperature :	Under 1100°C
Max temperature can reach in a short time :	1450°C
Acid tolerance:	30 times than Ceramics , 150 times than Stainless steel
Visible light transmittance :	above 93%
UV spectral region transmittance:	80%
Resistance value :	10000 times than ordinary glass
Annealing point:	1180°C
softening point:	1630°C
Strain point:	1100°C
Physical properties

Dimension Tolerance(mm)
Designation	OD	WT	Max. Siding	Max. Ovality	Max. Bow
1-3mm	±0.05	±0.05	0.05	0.05	1‰
3-10mm	±0.1	±0.1	0.1	0.15	2‰
10-20mm	±0.2	±0.1	0.1	0.2	2‰
20-30	±0.2	±0.15	0.15	0.2	2‰
30-40	±0.4	±0.15	0.2	0.2	2‰
40-50	±0.5	±0.2	0.25	0.25	2‰
50-65	±0.6	±0.2	0.35	0.25	2.5‰
65-85	±0.8	±0.3	0.45	0.3	2.5‰
85-100	±1	±0.3	0.5	0.5	2.5‰
100-150	±1.5	±0.4	0.5	0.8	3‰
150-200	±2	±0.6	0.6	1	4‰
200-300	±3	±0.8	0.7	2	5‰

Spectral Transmission at 1.0mm Thickness
nm	220	255	280	315	350	380	590	780
%	89	91	93	93	93	93	93.2	93.4

Chemical Composition, unit: PPM
K+Na	Ca	Fe	Al	Mg	Ti	Ba	Li	Cu
<10	<3	<1.5	<20	<1.0	<3.0	<0.2	<1.0	<0.5

Packing Method

Packing method:

Each product with a bubble bag, and put into carton box, and then packed in wooden case.

FAQ

Q: Are you a factory or trading company?

A: We are a factory.

Q: Where is your factory located? How can I visit there?

A: Our factory is located in Lianyungang, China, about 2hours by air from Shanghai.

Q: What is the material of your products?

A: The material is quartz, SiO2 99.99%

Q: Does your company support "Trade Assurance"?

A: Yes, up to 11000USD currently.

What is the payment term?

We accept T/T, PayPal, Western Union, L/C.

Q: How about the delivery time?

10-15 working day after payment received.

Q: How to contact Quickly?

Skype/Facebook/LinkedIn:tengtim at .

Mobile/WhatsApp: 86-15821957292.

Our Services

Sample service

Available in stock, samples will be sent as free, but freight cost is on customer side.

No stock, sample cost will be charged.

OEM service

Welcome OEM drawing.

Quick response and flexcible communication time

Feedback within 12hours, and free to communicate during 7:00~22:00.

Company Profile

Lianyungang Liaison Quartz Co., Ltd.

Lianyungang Liaison Quartz Co., Ltd. covers an area of more than 8,000 square meters, with a building area of 4,000 square meters. We have nearly 50 existing engineering and technical personnel, with an annual output of nearly 500 tons of high-quality quartz glass tubes. Our main products are transparent quartz glass tube, creamy white quartz glass tube, low-quartz glass tube, filter UV quartz glass tube and ozone quartz glass tube. We sell our products to clients in the United States, the UK, Japan, South Korea and more than 30 domestic and overseas manufacturers. Our company follows the tenet of "quality first, supremacy of users" and adheres to the aim of "integrity, efficient innovation and pragmatism". We adhere to the policy of "technical innovation". We pay attention to product quality and after-sales service. We welcome friends from at home and abroad to seek common development. Our company is located in Donghai County in Jiangsu Province. With highways, railways, and civil aviation and maritime networks, the transportation is extremely convenient. We set up a company in 2005 to import advanced quartz tube processing equipment, including quartz tube cutting, mouth and back burning, and flanging equipment. Our facilities are widely used in disinfection product, aquatic light, and heater production. We warmly welcome clients' presence in all sectors.
