Aluminum 3d Corrguated Lattice Paneling for External Walls Cladding

Aluminum 3d Corrguated Lattice Paneling for External Walls Cladding photo-1
Aluminum 3d Corrguated Lattice Paneling for External Walls Cladding photo-2
US$ 4 - 40 MOQ: 800 Square Meters
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ALCADEX
Model Number:
aluminum 3d corrguated lattice paneling for external walls cladding
Payment & Shipping
Payment Methods:
Port of Shipment:
shunde
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name ALCADEX
Model Number aluminum 3d corrguated lattice paneling for external walls cladding
Usage Outdoor
Function Anti-Static, Fireproof
Surface Treatment Anodized, Brushed, PE Coated, PVDF Coated, Other, PE Coated, PVDF Coated, Anodized, Brushed, PE Coated, PVDF Coated, aluminum 3d corrguated lattice paneling for external walls cladding, PE Coated, PVDF Coated

aluminum 3d corrguated lattice paneling for external walls cladding





aluminum 3d corrguated lattice paneling for external walls cladding
aluminum 3d corrguated lattice paneling for external walls claddingaluminum 3d corrguated lattice paneling for external walls claddingaluminum 3d corrguated lattice paneling for external walls cladding
aluminum 3d corrguated lattice paneling for external walls cladding





Product Description



It is also called aluminum lattice composite panel ,or improved honeycomb panel, that does not incur the expensive unit price of aluminum honeycomb panel but is stronger and has better quality than the latter. It is fully composed of metal materials without plastic ingredients, 100% environmentally friendly and fire resistant. Meanwhile, it has the feature of easy processing like the aluminum composite panel. The panel makes use of its unique physical structure with the small amount of aluminum material used. It is lighter than aluminum panels and has a flatter panel surface. Additionally, there are a variety of outer look selections available. The perfect surface presentation can be shown as a stone texture, wood texture or mirror surface.





 aluminum 3d corrguated lattice paneling for external walls claddingaluminum 3d corrguated lattice paneling for external walls cladding

 aluminum 3d corrguated lattice paneling for external walls cladding



aluminum 3d corrguated lattice paneling for external walls cladding



Width

1000/1220mm/ 1500mm

Panel Thickness

4mm

Aluminium Alloy

 AA3003

Aluminium Thickness

0.4-0.8mm

Coating

PE / PVDF /Wooden/Granite/Brush/Mirror

Core

Noncombustible Aluminum Core

Length

6000mm in maximum

Color

Solid / Metallic / Marble / Wooden / Brush / Glossy

MOQ

 800 SQM/standard size/color

1500 SQM/customized size/color

Brand / OEM

 ALCADEX® / Customized

Delivery

In 20 day after getting deposit and color confirmation

Payment Terms

  T/T / L/C / Western Union / Paypal

Packing

  Wooden Package or bulk loading





Data Comparison (with other facade products):



Item NameWeight/SqmFireproofFlatnessSurface FinishMaximum Panel Size
4mm 3D Panel3.6kgExcellentExcellent PE/PVDF,Brushed,Wood,Marble,Mirror 1.5M*L
10mm Alu Honeycomb Panel6.6kgExcellentExcellentPE/PVDF1.2M*L
6mm Alu Corrugated Panel4.6kgExcellentfairPE/PVDF,Brushed,Wood,Marble,Mirror1.2M*L
4mm Alu Composite Panel6.8kgGrade B1poorPE/PVDF2.0M*L
3.5mm Alu Solid Panel6.8kgExcellentpoorPE/PVDF1.3M*L







Item NameFlat-Wise Tension StrengthFlat-Wise Crush StrengthShear StrengthBending StrengthCylinder Peel Strength
4mm 3D Panel0.85Mpa4.39Mpa0.85Mpa161.9Mpa102.7 N.mm/mm
10mm Alu Honeycomb Panel>0.8Mpa>0.8Mpa>0.5MpaNo Standard Available50 N.mm/mm
6mm Alu Corrugated Panel>1.5Mpa>1.5MpaNo Standard Available>100Mpa40 N.mm/mm
4mm Alu Composite PanelNo Standard AvailableNo Standard Available29Mpa131MpaNo Standard Available





aluminum 3d corrguated lattice paneling for external walls cladding





Features:



A. Light Weight, compared to solid aluminum sheet, PE and FR core aluminum plastic composite panel;

B. Noncombustible Aluminum core;

C. Easy to fabricate compared to honeycomb panel;

D. More strength because of the corrugated core, compare to normal composite panel;

E. Cost effective, compared to honeycomb or FR composite panel;

F. More soud and heat insulation;

G. 100% recycling, aluminium metal only



Application:



A. Exterior wall-cladding

B. Interior wall decoration

C. Wallboard,ceiling,partition

D. Billboard,exhibition and notice board
