Home > Tools & Hardware > Hand Tools > Pliers > YJQ-MH992 Fined Tipped Crimp Tool Miniature Adjustable Plier Used in Electronic Connectors for 3362-204-1231 Deutsch

YJQ-MH992 Fined Tipped Crimp Tool Miniature Adjustable Plier Used in Electronic Connectors for 3362-204-1231 Deutsch

Name: YJQ-MH992 Fined Tipped Crimp Tool Miniature Adjustable Plier Used in Electronic Connectors for 3362-204-1231 Deutsch
Brand: Precisetool
SKU: 131353403
Availability: InStock

YJQ-MH992 Fined Tipped Crimp Tool Miniature Adjustable Plier Used in Electronic Connectors for 3362-204-1231 Deutsch thumbnail-1

YJQ-MH992 Fined Tipped Crimp Tool Miniature Adjustable Plier Used in Electronic Connectors for 3362-204-1231 Deutsch photo-1

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

Precisetool

Model Number:

YJQ-MH992

Contact Supplier Request Quote Chat Now

Jiaxing Jingrui Instrument&Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name Precisetool

Model Number YJQ-MH992

Type Other, hand crimp tool

Material Chrome Vanadium

Application Multi Functional

GENERAL INFORMATION

1. YJQ-MH992 is a fine tipped crimp tool which is widely used for the crimping of wires and contacts in electronic connectors.

2. Minimum wire crimp range: 36AWG (0.0127mm^2).

3. YJQ-MH992 refers to basic tool without positioners.

WORKING PRINCIPLES

1. Crimping Method

The crimping tool adopts curve propulsion mechanism, its applied force transfers through four curves in the head cavity of the right plier handle to the four indenters. The four intenders do the centripetal linear motion, which makes its front-end teeth crimp the contact to complete the crimping process. The cycle controlled precision ratchet assures the consistency of impression and the crimping quality of wires and contacts.

2. Crimping Range Adjustment

The crimping tool has eight selector numbers; the accurate data are listed as follows:

Selector NO.	Intender Working Diameter mm/INCH
Selector NO.	A GO	B NO GO
1	0.18/0.007	0.23/0.009
2	0.24/0.0095	0.29/0.0115
3	0.30/0.012	0.36/0.014
4	0.38/0.015	0.43/0.017
5	0.46/0.018	0.51/0.02
6	0.57/0.02255	0.64/0.025
7	0.66/0.026	0.72/0.0285
8	0.77/0.0305	0.84/0.033

3.Gaging Instructions

“GO” Gaging: keep the tool in fully closed position, insert the green “GO” gage end into the indenter, it should be easy to enter, otherwise, the selector gear is incorrect.

(CAUTION! DO NOT CRIMP GAGE!)

“NO GO” Gaging: keep the tool in fully closed position, insert the red “NO GO” end into the indenter, it can’t pass through completely, otherwise, the selector gear is incorrect.

(CAUTION! DO NOT CRIMP GAGE!)

CRIMPING INSTRUCTIONS

1. Insert the contact and prepare the wire through the indenter from the opposite side.

2. Squeeze the handles together until ratchet releases. Then the handle will return to its open position automatically.

MH992 APPLICATION

Tri-Tech	CROUSE HINDS P1315209-210
M39029/102-559 SKT	M39029/103-559 PIN
21-33664-7M Amphenol	21-3365-7M Amphenol
Rosenberger	Packets D-G Cook Inc
6362-223-1231 Deutsch	2999804004 Cinch
6362-226-1231, 6362-227-1231 Deutsch	Medical Implant Cochler
.028x.100LG Ferrule Accellent	#12 Quadrax Pin/Socket W. L. Gore & Assoc
3362-204-1231 Deutsch	859-006 Glenair
857-000-280 Ultra Precision	3061-0-19-xx-21-xx10-0 Mill-Max
ETH4-0011A-D ETH4-0012A-D Souriau	1996972-2 Tyco
610870 Deutsch	TEM Samtec
C-295-XX-X Samtec	1996972-2 Tyco
1996972-4 Tyco	BNC7T-P-C-M-ST-CA6-PIN Samtec

MH992 Application Market

civil aviation & military plan/ helicopter	weapon launcher
aviation	railway
physical geography & maritime	manufacturing industry & environmental protection
Instrument	racing car
nuclear industry	other fields

CAUTIONS

Keep the crimping tool and other units clean and properly stored when not in use or no operator maintenance.
Don’t try to immerse tools in cleaning solution or spray oil into tools to lubricate.
If finding anomalies due to the incorrect ways, don’t attempt to disassemble tools or make repairs. Please stop using it and connect us as soon as possible, our company will offer complete refurbishing and recalibration services.
