Reasons of high quality :please see the following detailed photos.
The following detailed photos taken in SNOWKEY factory. Pirates of those photos is not allowed!
The pursuit of the perfect appearance -from rigorous attitude ;
If you would like to enjoy the diamond grade edible tube ice, please choose the tube ice evaporator made by excellent material and best processing technology.
Best processing technology -from advanced processing equipments ;
(Pressure vessel: Pressure vessel with ASME authentication; professional security manufacturing processes)
Excellent material -from rigorous selection processes for decades;
(Material: SUS304; Clean, sanitary, comply with food grade security standard)
Material Processing--CNC laser cutting machine :
Evaporator Processing--CNC electronic processing for the inner wall of the evaporator :
Equipment Insatllation--the most skilled technical workers, the most rigorous working attitude:
Electrical Installation--the most experienced electrical workers:
Intelligent control -from SNOWKEY full automatic electric box;
(Material: Electrical components imported from international famous brands, such as Schneider, Siemens.,etc)
Performance Testing--Product performance testing center:
Logistics Packaging,Loading And Transport:
Installation And Training On Site--the most professional engineer and the most effective working:
The Strongest After-Sales Service:
Oversea Projects Examples:
Professional and efficient after sale service level -from Snowkey professional technical team all over the world. We are right here on your side!
Tube ice machine application
1 Human consumption ice plant
2 Port ice plant
3 Coffee shop,bar,and hotel,etc
4 Supermarket,convenienience shop and restaurant,etc
5 Aquatic products and food fresh preservation
6 Logistic fresh preservation
7 Cgemical and concrete projects
Tube ice machine work conditions
Power supply:Full electric system complying with the general international standard
Ambient temperature:33°C
Water supply temperature:20°C
(water quality should be pure,Water filter and softening is suggesteded for places with hard water quality.)
Tube ice specification:φ22,φ29,φ35,φ38 and φ41(standardard tube ice outer diameter,inner diametr 3mm-15mm )
Limit work comditions(variable wiork condions):Ambient temp.:5°C~40°C; Water suppl:0.5°C~30°C.
Refrigrant:R22,R404A,R507A,R717
Tube ice machine features
1 High reliability and low fault failure
——80% components of the tube ice maker system are world famous brand. Through decades of research and practice, SNOWKEY products can run continuously without fault and keep good run and stable ice output even in ambient temperature 5°C-4O°C. Special designed machine can even allow normal run in the most atrocious conditionns(-5°C—+56°C).
2 Scientific design and advanced processing technique
——SNOWKEY tube ice maker has scientific design and can also make the best ice making system according to customer's actual demand, with world leading ice making technology and processing and testing equipments. Each part is processed with strict technique requirement and strictly tested before using.
3 Sanitary
——Quality and sanitary tube ice maker is the aim of SNOWKEY. All parts contacting with water are made of stainless steel SUSSO4 or SUS316L and PE material. Tube ice produced is sanitary without smell, meeting HACCP and PDA certificate requirement.
4 Efficient and environment friendly
——With stable continuous running, SNOWKEY tube ice maker realizes the running without energy wasting. Compared with other ice making equipments, SNOWKEY tube ice maker boasts the advantages of compact structure, small area, low production cost, high refrigeratjon effect and low energy consumption, etc.
5 Module design and simple maintenance
——SNOWKEY tube ice maker has module design for simple maintenance on site. Tube ice maker can be installed inside a standard container, very suitable for frequent moving occasion.
TIM tube ice maker technical parameter:
| Model | TIM10 | TIM30 | TIM50 | TIM100 | TIM150 | TIM200 | TIM250 | TIM300 | TIM400 | TIM500 | TIM700 | TIM1000 |
| Ice capacity -φ22(t/d) | 1.04 | 3.12 | 5.2 | 10.4 | 15.6 | 20.8 | 26 | 31.2 | 41.6 | 52 | 72.8 | 104 |
| Ice capacity -φ29(t/d) | 1 | 3 | 5 | 10 | 15 | 20 | 25 | 30 | 40 | 50 | 70 | 100 |
| Ice capacity -φ35(t/d) | 0.9 | 2.7 | 4.5 | 9 | 13.5 | 18 | 22.5 | 27 | 36 | 45 | 63 | 90 |
| Installation power(kw) | 6.5 | 15 | 25 | 46 | 65 | 85 | 105 | 125 | 165 | 200 | 260 | 350 |
| Running power(kw) | 4 | 9 | 16 | 32 | 45 | 64 | 80 | 96 | 125 | 150 | 210 | 300 |
| Main shaft power (kw) | 0.25 | 0.37 | 0.55 | 0.75 | 0.75 | 0.75 | 0.75 | 1.1 | 1.1 | 1.1 | 1.5 | 1.5 |
| Water pump power(kw) | 0.25 | 0.37 | 0.55 | 0.55 | 0.75 | 0.75 | 0.75 | 1.1 | 1.1 | 1.1 | 1.1 | 1.1 |
| Running weight(kg) | 800 | 1200 | 1500 | 2500 | 3500 | 6400 | 7200 | 8200 | 9800 | 12000 | 15000 | 18000 |
Snowkey Certificates:
Notice:
1,SNOWKEY standard design conditions:
Ambient temperature is 33°C,water supply temperature is 20°C;
While if your local conditions is different from it,then you can choose the ambient temperature limit from 5~40°C and the water supply temperature limit from 5~30°C;,
2,SNOWKEY tube ice specification:
Ø22,29,35 and 41 standard tube ice outer diameter, inner diameter 3mm-15mm;
3,SNOWKEY power supply:
Full electric system complying with the general international standard;
4,SNOWKEY delivery for tube ice machine:
With wooden cases;In 20 foot container;
1-10 ton/day delivery:30~35 working days;
5,SNOWKEY tube ice machine application field :
1 Human consumption ice plant
2 Port ice plant
3 Coffee shop,bar,and hotel,etc
4 Supermarket,convenienience shop and restaurant,etc
5 Aquatic products and food fresh preservation
6 Logistic fresh preservation
7 Cgemical and concrete projects
Features:
1)Tube Ice Machine has a special ice making method can get rid of the impurities in water.
2)Ice making method uses water circulation to meet the clean demand. The ice is sparkling and transparent.
3)The ice making time and production is stable, that is suitable to control your business.
4)The shape of ice is suitable for storage and delivery, it can be used in all kinds of business.
Tube Ice Machine production capacity:
1) TIM50: 5,000kg/24hr
2) TIM100: 10,000kg/24hr
3) TIM150: 15,000kg/24hr
4) TIM200: 20,000kg/24hr
5) TIM300: 30,000kg/24hr
6) TIM400: 40,000kg/24hr
7) TIM500: 50,000kg/24hr
8) TIM600: 60,000kg/24hr
9) TIM800: 80,000kg/24hr
10) TIM1000: 100,000kg/24hr
