Specifications
1.Edible Tube Ice Machine2.Stable of production
3.Easy for storage
4.High reliability
5.Certification:CE,ISO9001.ISO14001
Tube ice machine application
1 Human consumption ice plant
2 Port ice plant
3 Coffee shop,bar,and hotel,etc
4 Supermarket,convenienience shop and restaurant,etc
5 Aquatic products and food fresh preservation
6 Logistic fresh preservation
7 Cgemical and concrete projects
Tube ice machine work conditions
Power supply: Full electric system complying with the general international standard
Ambient temperature: 33°C
Water supply temperature: 20°C (water quality should be pure,Water filter and softening is suggesteded for places with hard water quality.)
Tube ice specification: φ22,φ29,φ35,φ38 and φ41(standardard tube ice outer diameter,inner diametr 3mm-15mm )
Limit work comditions Ambient temp.:5°C~40°C; Water suppl:0.5°C~30°C.
Refrigrant: R22,R404A,R507A,R717
Tube ice machine features
1 High reliability and low fault failure
80% components of the tube ice maker system are world famous brand. Through decades of research and practice, SNOWKEY products can run continuously without fault and keep good run and stable ice output even in ambient temperature 5°C-4O°C. Special designed machine can even allow normal run in the most atrocious conditionns(-5°C—+56°C).
2 Scientific design and advanced processing technique
SNOWKEY tube ice maker has scientific design and can also make the best ice making system according to customer's actual demand, with world leading ice making technology and processing and testing equipments. Each part is processed with strict technique requirement and strictly tested before using.
3 Sanitary
Quality and sanitary tube ice maker is the aim of SNOWKEY. All parts contacting with water are made of stainless steel SUSSO4 or SUS316L and PE material. Tube ice produced is sanitary without smell, meeting HACCP and PDA certificate requirement.
4 Efficient and environment friendly
With stable continuous running, SNOWKEY tube ice maker realizes the running without energy wasting. Compared with other ice making equipments, SNOWKEY tube ice maker boasts the advantages of compact structure, small area, low production cost, high refrigeratjon effect and low energy consumption, etc.
5 Module design and simple maintenance
SNOWKEY tube ice maker has module design for simple maintenance on site. Tube ice maker can be installed inside a standard container, very suitable for frequent moving occasion.
TIM tube ice maker technical parameter:
| Model | TIM10 | TIM30 | TIM50 | TIM100 | TIM150 | TIM200 | TIM250 | TIM300 | TIM400 | TIM500 | TIM700 | TIM1000 |
| Ice capacity -φ22(t/d) | 1.04 | 3.12 | 5.2 | 10.4 | 15.6 | 20.8 | 26 | 31.2 | 41.6 | 52 | 72.8 | 104 |
| Ice capacity -φ29(t/d) | 1 | 3 | 5 | 10 | 15 | 20 | 25 | 30 | 40 | 50 | 70 | 100 |
| Ice capacity -φ35(t/d) | 0.9 | 2.7 | 4.5 | 9 | 13.5 | 18 | 22.5 | 27 | 36 | 45 | 63 | 90 |
| Installation power(kw) | 6.5 | 15 | 25 | 46 | 65 | 85 | 105 | 125 | 165 | 200 | 260 | 350 |
| Running power(kw) | 4 | 9 | 16 | 32 | 45 | 64 | 80 | 96 | 125 | 150 | 210 | 300 |
| Main shaft power (kw) | 0.25 | 0.37 | 0.55 | 0.75 | 0.75 | 0.75 | 0.75 | 1.1 | 1.1 | 1.1 | 1.5 | 1.5 |
| Water pump power(kw) | 0.25 | 0.37 | 0.55 | 0.55 | 0.75 | 0.75 | 0.75 | 1.1 | 1.1 | 1.1 | 1.1 | 1.1 |
| Running weight(kg) | 800 | 1200 | 1500 | 2500 | 3500 | 6400 | 7200 | 8200 | 9800 | 12000 | 15000 | 18000 |
