CHINA TOP1 Air Delivery System for Delivering Flake Ice Snow for SkiUS$ 5,000 - 30,000MOQ: 1 Set
Snowkey Air Delivery System feature:
Pneumatic delivery system can be adopted when limited by the service occasion or the ice destination is too far away. Moreover, it can deliver ice to several ice destinations.
The pneumatic ice delivery system consists of high-capacity-low-pressure air blower, air cooling system, rotary valve, pipeline and control system, etc.The longest horizontal delivery distance can reach to 200 meters, or vertical delivery distance can surpass 25 meters.
There are manual and automatic shunt valve for your option, so as to deliver to several ice destinations. And ice-air separator can be adopted for the ice to be delivered directly to the mixing machine. The air cooling device is adopted to make the temperature inside the delivery pipeline below 5. The pneumatic ice delivery system can meet greatest demand for ice.
| Model | Delivery capacity | Horizontal delivery distance/m | Installation Power/kw |
| AID-6 | 6 | 200 | 22 |
| AID-10 | 10 | 200 | 22 |
| AID-12 | 12 | 200 | 37 |
| AID-15 | 15 | 200 | 37 |
| AID-20 | 20 | 200 | 45 |
| AID-25 | 25 | 150 | 45 |
| AID-30 | 30 | 150 | 55 |
| AID-45 | 45 | 100 | 75 |
