Top Mount Fiberglass Swimming Pool Sand Filter
Functions
Maximum working pressure: 250kPa/ 36psi/ 2.5bar
Factory testing pressure: 400kPa/58psi/ 4.0bar
Size of silica sand: 0.5-0.8mm
Maximum filtration velocity: 50m3/h/m2
Maximum water temperature: 43 degree
Technical Characteristics
dia-350, 0.09 sq meter(filter area), 1.5’’/50mm(valve connections) 4.32 cbm/h(flow rate) 20kg(sand)
dia-400, 0.13 sq meter(filter area), 1.5’’/50mm(valve connections) 6.48 cbm/h(flow rate) 35kg(sand)
dia-450, 0.16 sq meter(filter area), 1.5’’/50mm(valve connections) 8.1 cbm/h(flow rate) 45kg(sand)
dia-500, 0.22 sq meter(filter area), 1.5’’/50mm(valve connections) 11.1 cbm/h(flow rate) 85kg(sand)
dia-650, 0.32 sq meter(filter area), 1.5’’/50mm(valve connections) 15.6 cbm/h(flow rate) 145kg(sand)
dia-700, 0.40 sq meter(filter area), 1.5’’/50mm(valve connections) 19.5 cbm/h(flow rate) 210kg(sand)
dia-700(B), 0.41 sq meter(filter area), 2’’/63mm(valve connections) 20.2cbm/h(flow rate) 215kg(sand)
dia-800, 0.50 sq meter(filter area), 2’’/63mm(valve connections) 24.9cbm/h(flow rate) 355kg(sand)
dia-700, 0.64 sq meter(filter area), 2.0’’/63mm(valve connections) 31.2 cbm/h(flow rate) 470kg(sand)
...........
dia-1000, 0.40 sq meter(filter area), 2’’/63mm(valve connections) 39.0 cbm/h(flow rate) 620kg(sand)
dia-1200, 0.40 sq meter(filter area), 2’’/63mm(valve connections) 51.6 cbm/h(flow rate) 860kg(sand)
Pictures
About Us
Our company, Guangzhou Vigor Health Equipment Co., Ltd is professional in spa, sauna, swimming pool equipment. We have been in this area for more than 15 years and our own factory is located in Qingyuan City. Welcome to visit our factory.
