Home > Products > Jacketed Glass Reactor > Desktop Jacketed Glass Reactor
Desktop Jacketed Glass Reactor
- 10 Unit / Units per Month
- Shanghai
- Lab Jacketed Glass Reactor 10 Liter Chemical Reactor for Research
- Mini Lab Jacketed Glass Reactor High Borosilicate Reaction Vessel
- Customized Industrial Chemical Reaction Jacketed Glass Reactor
- GG-17 Jacketed Glass Reactor Heating and Cooling Circulator Mixer Reactor
- 1-5L Single Layer Pyrex Borosilicate Tank Stirred Heated Glass Reactor
- 10L Digital Extraction Synthesis Laboratory Single Glass Reactor
Product Details
Condition: | New | Automatic Grade: | Automatic | Type: | Tank Reactor |
Brand Name: | Guojing | Model Number: | JR-S1-JRS5 | Voltage: | 220v |
Power(W): | 40-90w | Dimension(L*W*H): | 30x35x80 - 40x50x110cm | Weight: | 15-20kg |
Warranty: | 1 Year | After-sales Service Provided: | No overseas service provided |
Product Description
Desktop Jacketed Glass Reactor
Jacketed glass reactor is an ideal instrument in pharmacy, biology, fine chemistry and material synthesis. With menstruum in inlayer and heating or cooling source in interlayers, jacketed glass reactor can perform reflux and distill under airproof condition.
Our products Desktop Jacketed Glass Reactor Series could choose two kinds of reactor cap:glass or PTFE.
- NS24 Reflux condenser
- NS24 Pressure equalizing funnel
- NS19 Multifunctional valve
- NS19 Thermowell
Desktop Jacketed Glass Reactor | |||
Model | JR-S1 | JR-S2 | JR-S5 |
Reaction Flask | 1L | 2L | 5L |
Diameter of Flask Lid | 150mm | 150mm | 180mm |
Material of Flask Lid | Glass / PTFE | Glass / PTFE | Glass / PTFE |
Temp Range | -80-250°C | -80-250°C | -80-250°C |
Vacuum Level | >0.095MPa | >0.095MPa | >0.095MPa |
Positive Pressure | <0.07MPa | <0.07MPa | <0.07MPa |
Motor Power | 40W | 40W | 90W |
Rotary Speed (rpm) | 50-1200 | 50-1200 | 50-1200 |
Dimensions (cm) | 30x35x80 | 30x35x80 | 40x50x110 |
Power Supply | 220V/5A | 220V/5A | 220V/5A |
Price (USD) | 800-830 | 830-860 | 1350-1400 |
Parts & Accessories
Customized pilot plant solutions
We also provide customized pilot plant solutions to meet the need of various process. If you would like to know us, just contact us.
Company Information
Guojing(Shanghai)laboratory equipment Co.,Ltd. We focus on manufacturing and sales of laboratory equipment and experimental apparatus, main products are rotary evaporator, jacketed glass reactor, heating bath and constant speed blender. We are one of the earliest manufacturers engaged in the development and manufacturing in this area.
Companies adhere to the professional, convenient, honest service concept, is constantly getting the recognition of domestic and foreign well-known brands. We will, as always, for the vast number of scientific research workers to provide safe, efficient and stable scientific support equipment, for the development of cutting-edge technology to make their own contribution to the ability.
Production factory was established in Shanghai in 2001. Since its inception, has been the heritage of independent development, independent production of enterprises to create ideas, relying on long-term research and development experience and technology, as well as a high degree of credibility of the market development system, and continue to grow and grow. In 2011, the company moved to the production base in the suburbs of Shanghai, so that manufacturing and technical services more quickly.
Contact Us
- Guojing (Shanghai) Laboratory Equipment Co., Ltd.
- AddressRoom 603, Jinqiao Building, No. 1389, Jinqiao Road
