Excellent manufacturer for cable carrier
Features:
1.No need install rail
2.No damage to the floor
3.It can realize double way moving and 360 degree turning.
4.DC drive and heavy loading capacity.
5.Small turning radius, flexible operation.
6.Braking distance is short,and have alarming system.
Material handling cart battery powered
Working principle:
KPW series steerable transfer trolley is a kind of trackless material handling trolley. It is powered by storage battery. The transfer trolley is controlled to go forward, backward, turn left, turn right, adjust speed through PLC and speed controller.
Moral cart adopt battery power, DC motor drives, large capacity, stable start, do not rely on rail, two-way travel. Hydraulic steering mechanism ensures tight turning radius, enabling 360 ° turn in a small space.
Moral cart has crash protection and installed sound and light alarm systems. adopt electromagnetic brake, response speed, braking distance is short, safe to use. Wheels has polyurethane wheels and tubeless rubber wheels, without damaging the floor coatings
Noted:If you have inquiry, pls let us know loading capacity?and platform size??thanks
Model |
KPX-10 |
KPX-20 |
KPX-50 |
KPX-100 |
KPX-150 |
|
Rated Load(t) |
10 |
20 |
50 |
100 |
150 |
|
Table Size(mm) |
Length(L) |
2000 |
4000 |
5500 |
6500 |
10000 |
Width(W) |
1500 |
2200 |
2500 |
2800 |
3000 |
|
Height(H) |
450 |
550 |
650 |
850 |
1200 |
|
Rail Inner Gauge(mm) |
1435 |
1435 |
1435 |
2000 |
2000 |
|
Wheel Diameter(mm) |
400 |
400 |
500 |
600 |
600 |
|
Wheel Quantity |
4 |
4 |
4 |
4 |
6 |
|
Ground Clearance(mm) |
50 |
50 |
50 |
100 |
100 |
|
Running Speed(min) |
25 |
20 |
20 |
20 |
18 |
|
Motor Power(kw) |
2 |
2.5 |
5.5 |
11 |
15 |
|
Battery(v) |
48 |
48 |
48 |
48 |
48 |
|
Recommended Rail Model |
P15 |
P24 |
P43 |
QU100 |
QU100 |
|
