CNG/LPG PVC-Coated Copper Tube
Description:
Copper Tube made from Deoxidized High Phosphorus Copper or Deoxidized Low Phosphorus Copper; Cu≥99.9%; Good join ability, Long life (50years), and Bendable.
PVC Sheath made from eco-friendly material; ROHS assured; Good Weatherability, Long life(10years), and Beautiful Appearance.
Standard:
As per ASTM B68, AS1572, JIS H3300, EN12449 and BS2871-2.
How Furnished:
Pancake Coil, Bunch Coil, Straight Length;
*If customers need other forms, please check with us for the possibility.
With Wire or without Wire:
We can supply tube-with-wire type, coated by PVC Sheath, as per customers’ choice. The tube-with-wire type is unique design with our patent specially for CNG/LPG transport, which can improve efficiency and reduce cost for installation of Auto CNG/LPG system.
Specification:
Model No. |
Copper Tube |
PVC Sheath |
Working Pressure (psi) |
|||
O.D.XW.T. |
Length |
Wall Thick. |
Length |
Color |
||
FSG-001 |
1/4”x20swg |
7.5mtr/25feet 15mtr/50feet 30mtr/100feet
|
1/16” |
7.5mtr/25feet 15mtr/50feet 30mtr/100feet
|
1Red/ Blue/ Yellow/ White/ Black
|
1891 |
FSG-002 |
5/16”x20swg |
1/16” |
1513 |
|||
FSG-003 |
3/8”x20swg |
1/16” |
1265 |
|||
FSG-004 |
1/2”x20swg |
1/16” |
945 |
|||
FSG-005 |
6mmx0.8mm |
1.5mm |
1760 |
|||
FSG-006 |
6mmx1mm |
1.5mm |
2211 |
|||
FSG-007 |
8mmx1mm |
1.5mm |
1658 |
|||
FSG-008 |
10mmx1mm |
1.5mm |
1324 |
|||
FSG-009 |
12mmx1mm |
1.5mm |
1091 |
|||
