Home > Instruments & Meters > Meter for Liquid & Gas > Liquid Level Meter > High Level/low Level Alarm Level Electromechanic for Dust Measuring Instrument
High Level/low Level Alarm Level Electromechanic for Dust Measuring Instrument
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Taiwan, China
Brand Name:
FineTek
Model Number:
EE 300
Payment & Shipping
Payment Methods:
Port of Shipment:
Keelung port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Electromechanical Level Measurement Sensor Level Instruments to Measure SolidNegotiableMOQ: 1 Unit -
FineTek High Quality Solid Measure Transmitter Instruments Capacitive SensorNegotiableMOQ: 1 Unit
-
Diesel Tank Measuring FineTek EB Explosion Proof Capacitive Level SensorNegotiableMOQ: 1 Unit
-
High Quality FineTek RF Capacitive Admittance Liquid Level TransmittersNegotiableMOQ: 1 Unit
-
Mining Cement Application Using RF Admittance Capacitive Transducer Sensor LevelNegotiableMOQ: 1 Unit
Place of Origin
Taiwan, China
Brand Name
FineTek
Model Number
EE 300
EE200 series Electro-Mechanical Level Measuring System is consisted of plumb, cable wire, measuring pulley, position sensor, and control board. When measuring, the sensing weight will drop down and cable wire will rotate the measuring pulley. Position sensor and control board will calculate the distance of travel of the sensing weight(medium level) based on how many rotations measuring pulley accomplishes.
- 1 Measuring result immune from the interference of environment such as sound waves, dust, capacitance, or temperature change.
- User-friendly with microprocessor-based design.
- High level and low level alarm.
- LCD Dot matrix: 8 x 2.
- Analog output: 4-20mA dc.
- Pulse output: Transistor output(NPN/PNP), Relay output(3A/250Vac)
- Cable Break Alarm: System will detect cable broken during measuring.
- Plumb Buried Alarm: System will detect plumb buried by the medium.
- 4 Forms of Start Mode: auto start, manual start, intelligent start, and external start.
- Intelligent Start: Measuring interval is inverse proportional to medium level.
- Auto Return Setup: Prevent sensing weight from sliding into the tank to damage the equipment when tank is empty.
- Material Fill-Up Protection: Reduce the possibility of plumb being buried.
- Measuring range of 30m.
- RS485 communication protocol.
- Various selections of plumb.
- The result of measurement is not affected by environmental factors as sound waves, dust, static electricity, humidity and dielectric etc.
- Can be widely applied for applications in mining, cement, petrochemical, feeding and power plants.
- Suitable for different variety of materials as powder, pellet, liquid, and also good for open tanks or sealed tank with no inner pressure inside.
- Working perfectly with software of material management system (MMS), accurately monitoring and managing the level of materials inside the tank.
- It features multifunction in on,needn’t extra controlling box, connecting to panel for a immediate usage is available.
