Product Details
| Place of Origin | Taiwan, China | Brand Name | FineTek | |
| Model Number | SC series |
Product Description
The vibrating probe of level switch operated by using two piezoelectric elements built-in on vibration tube. The first piezoelectric element triggered by pulse signal that created from circuit to transport vibration energy out, and the other piezoelectric element receives the vibration and transmits it to output electric signal. While the probe contacts material, the detection signal will be decayed and the vibration will hold and send out the relay on.
Vibrating probe of level switch provides reliable & maintenance-free for bulk solids. Just a simple mounting and calibration procedure that keep your facility in save and monitoring. This device can withstand fiercely lateral loads and static electricity.
For friendly use, Fail-safe is equipped as standard to prevent malfunction caused by power shortage.
- Sturdy and durable design. No calibration needed.
- Special design to avoid the accumulation of material on probe.
- High / Low fail safe modes
- Field-operatable in sensitivity adjustment to fit versatile density of material.

Solid Level Detection
Powders:
Powdered milk, flour, spices, coffee beans, coffee powder, tea, salt, sugar, grains, chocolate Tobacco, powdered cellulose, powdered clay, polystyrene powder, dry soot, soda ash, coal ash
Granular & plastics:
Gravel, glass fine power, granular plastics, foundry sand, cements, plastic pellets
Chip or pellet like:
Frozen potato chips, beans, peanuts, sweets and candy, animal / pet food Wood shavings, chalk, steering chips, styrofoams, charcoals
