Cable Conveyor Belt

Cable Conveyor Belt thumbnail-1
Cable Conveyor Belt photo-1
Negotiable MOQ: 200 Meters (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
LONGLI
Model Number:
LL
Contact Supplier Request Quote Chat Now
Shandong Longli Belt Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name LONGLI
Model Number LL

Specifications

1.High tensile strength
2.Small elongation in use
3.lesser elongation in use
4.Good troughabilit

Steel cordconveyor belt
1.High tensile strength
2.Small elongation in use
3.lesser elongation in use
4.Good troughabilit

Steel cord conveyor belt:

it is widely used in material delivery for coal/coke, mine, harbour, metallurgy, electric power and chemical industry



Specification:

ST630 ST800 ST1000 ST1250 ST1600 ST2000 ST2500 ST3150 ST3500 ST4000 ST4500 ST5000 ST5400 ST6300
Tensile Strength (N/mm) 630 800 1000 1250 1600 2000 2500 3150 3500 4000 4500 5000 5400 6300
Max Diameter of Cord(mm) 3 3.5 4 4.5 5 6 7.5 8.1 8.6 8.9/ 9.7 10.9 11.3 12.3
Pitch of Cord(mm) 10 10 12 12 12 12 15 15 15 15 16 17 17 18
Top Rubber Cover Thickness  (mm) 5 5 6 6 6 8 8 8 8 8 8 8.5 9 10
Bottom Rubber Cover Thickness (mm) 5 5 6 6 6 8 8 8 8 8 8 8.5 9 10





Width (mm) Cord Number
800 75 75 63 63 63 63 50 50 50
1000 95 95 79 79 79 79 64 64 64 64 59 55 55 54
1200 113 113 94 94 94 94 76 76 77 77 71 66 66 63
1400 133 133 111 111 111 111 89 89 90 90 84 78 78 74
1600 151 151 126 126 126 126 101 101 104 104 96 90 90 85
1800   171 143 143 143 143 114 114 117 117 109 102 102 96
2000     159 159 159 159 128 128 130 130 121 113 113 107
2200           176 141 141 144 144 134 125 125 118
2400           193 155 155 157 157 146 137 137 129
2600           209 168 168 170 170 159 149 149 140
2800                 184 184 171 161 161





Cover rubber property and grades :

Test items
Property indexes
GB9770-2001
DIN22131
D
H
L
P
W
X
Y

Tdnsile strngth

 Mpa >=

18
25
20

14

18

25

20

Pull to break the elongation rate

 % >=

400
450
400

350

400

450

400

after aging(70°C,7D)
Change rate of tensile strength Change rate of elongation

 %

-25~+25
-25~+25
-25~+25

25~+25

-25~+25

-25~+25

-25~+25

Abrasion

 <=

90MM3
120MM3
150MM3

200MM3

90MM3

120MM3

150mm3

 Cable conveyor beltCable conveyor beltCable conveyor belt
