Hydraulic Pump Using High Quality Thermal Dispersion Flow Switch Level Sensor
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Taiwan, China
Brand Name:
FineTek
Model Number:
SP series
Payment & Shipping
Payment Methods:
Port of Shipment:
Keelung port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Magnetic Generator Magnetic Level Float Switch Position SensorNegotiableMOQ: 1 Piece -
Magnetic Level Sensor Float Type Level Switch Liquid Measuring InstrumentNegotiableMOQ: 1 Piece
-
Multi-point Magnetic Sensor Switch Float Ball Level Gauge Acid Level SensorNegotiableMOQ: 1 Piece
-
FineTek Magnetic Float Level Sensor Water Level Controller Float SwitchNegotiableMOQ: 1 Piece
-
High Capability of Customization Magnetic Float Switch for Water TreatmentNegotiableMOQ: 1 Piece
Place of Origin
Taiwan, China
Brand Name
FineTek
Model Number
SP series
The Thermal Flow Switch Monitor is based on the principle of thermal dispersion. A typical configuration uses two Temperature Detectors set within the tip of the sensor. One Temperature Detector is heated a few degrees above the other one. As the process medium flows over the tip of the sensor it disperses some of the heat from the heated Temperature Detector. The delta temperature is a function of flow velocity and converted into electronic signal. The open collector changes state once the set point has been reached.
- Detection of flow velocities in pipes
- LED functions Display
- Open collector alarm output
- Relay out/put
- Measuring Range(Speed): Water: 1~150 cm/s ; Oil: 3~300 cm/s
- Material SUS304, 316, PVDF, PP, available
- Petrochemicals
- Hydroelectric plants
- Shipyard
- HVAC Systems
- Steel Industry Food and Beverage
- Pharmaceutical
- Optics and Semiconductor Industry
- Cooling pipes flow control
*Any pipes carrying liquid where flow measurement is needed.
