Icecream Display Freezer With 12 Tubs

 Icecream Display Freezer with 12 Tubs

  Icecream Display Freezer     Feature

 1.Our   Icecream Display Freezer has been tested at +35°C in 70% relative humidity
2. the ice cream display area has a 8% incline offering maximum visibility

 3. Automatically and quickly defrost by hot gas-Low noise level

 4. The internal structural in 100% stainless steel 304 material ,structural strength and hygiene.

 5. Artificial Marble or S/S 304 can be chose for outside structural/base

 6. Insulation in polyurethane thickness 80 mm, guaranteeing minimal ispersion and greatly reduced running costs

 ed to guarantee excellent performances & low consumption with powered  Danfoss/Tecumseh/Aspera  compressor.

 8. Ventilated cooling system with fan assisted cooling for evey temperature on all place.

 9. Refrigerant R404A
10. Tempered curved glass with defogging heating wires

 11. Easy setting by digital temperature control board

 12. Available in the 8- 12 - 16 - 18 - 20 - 24 - 12 + 12 flavors

 14. CE certification for Europe and 3C certification in China

 15. with  double evaporators

 Options for your choice:

 1.you can choose the lamp /LED lights

 2.the base Artificial Marble color

 3.the pan size and quantity
3Liters ,4Liters,4.5Liters or 5 Liters S/S Ice cream Pans or plastic pan
4.can paste your logo sticker

Icecream display freezer    Product Describe

Model : DSCF-1200

Unit DIMENSION(mm) : 1200x1130x1270 mm

Pan Quantity: DSCF-1500 12 Pans
                      Pan size :1/4 pan (265mm*152mm)
1.Temperature:-15°C~-22°C
2.outside temperature limit and humidity limit:33°C    60%
3.Back door : Acrylic glass door
4.Inner/exterior /back board  material :Stainless steel 304
5.inner lights: LED /Lamp Lighting
6.Refrigerant:R404a
7.quantity of evaporator: 2
pressor: Aspera (1HP*2)
9. electron temperature control &Automatic frost treatment
9.Ambient Temperature: 0~+38°C
10.machine power (w):1580W
11. Color: green/white/red

12.with logo sticker

Icecream display freezer  More size for your choice :

 Icecream display freezer  Details

More color for your choice:

Unfished Icecream display freezer

Icecream display freezer   Trays

As to the container , we can do the square pan or the round plate .

The square trays size is  1/2: 325mm*265mm

                                              1/4 : 265mm*162mm

                                              1/3 : 325mm*176mm

The square pan depth can be 100/150mm

The round pan size : Ø25*20H

Icecream display freezer   back can by plastic curtain  or Acrylic  glass door

plastic curtain

Acrylic  glass door

Testing room for our   Icecream display freezer

( Every   Icecream display freezer    must to be testing before delivery)

Refrigeration Equipment : (Famous brand Aspera/Tecumseh/Danfoss /compressor) All imported

 Icecream display freezer     Base

 artificial stone & marble for two sides ( moistureproof and lose colour ) much more durable !!!

The color can is  optional !!!

More series for  our  Icecream display freezer

Icecream display freezer   package :

 Icecream display freezer drainage system

 Our factory & production line :
