SSMA Male Stainless, SSMA rf Connector

FOB Price

Negotiable / Piece

1000 Pieces(Min. Order)

Port Shenzhen
Payment TermsT/T Money Gram Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Twinlink	Model Number	50SMA2S55-J41
Type	Other, SSMA, SSMA	Application	RF
Gender	Male

Product Description

Specifications

SSMA Male Stainless, SSMA rf connector
1.factory/manufacturer
2.OEM&ODM
3.MIL-C-39012,

SSMA Male Stainless, SSMA rf connector

Mechanical Characteristics
ELECTRICAL DATA
Impedance	50Ω
Frequency range (for connector interface)	DC~18GHz
Dielectric withstanding voltage (at sea level)	≥750-1500V,50Hz (depending on cable)
Working voltage (at sea level)	≥250-500V,50Hz (sea level) / ≥65-125V,50Hz (Height 21000M)
Insulation resistance	≥ 5000 mΩ
Contact resistance	Inner conductor: ≤3mΩ
Contact resistance	Outer conductor: ≤2.5mΩ
RF leakage(2-3GHZ)	Flexible: ≥60dB
RF leakage(2-3GHZ)	Semi-rigid cable: ≥100dB

MECHANICAL DATA
Coupling nut torque	0.8Nm--1.1Nm / 7.1 in.lbs--9.7 in.lbs
Coupling nut retention force	≥270N / 60.7 lbs
Contact captivation axial	≥27N / 6.1 lbs
Durability (matings)	≤500

ENVIRONMENTAL DATA
Temperature range	-65°C to +165°C

MATERIAL DATA
Bodies, outer contacts	Beryllium copper--Au plating
	Stainless steel--Passivation
	Brass--Au plated / ternary alloy plating
	Phosphor bronze --Au plating
Pin contacts	Brass/Beryllium copper--Au plating
Socket contacts	Beryllium copper / Phosphor bronze--Au plating
Crimp ferrules	Brass--Au plating
Insulator	PTFE
Gaskets	Silicone rubber

Minimum Testing Standard

1. Waterproof:
IP68 grade, drop into 1 meter deep water, and take it out after 24 hours later, there is no water seepage indication arriving.
2. Salt Mist Testing
5% concentration salt mist testing standard
Au plated, minimum 96 hours
Ag plated, minimum 336 hours
Ternary alloy plated, minimum 336 hours
3. Aging testing
Aging testing equipment temperature standard is minimum 85 degree, take the production out after 8 hours later from the machine, the mechanical characteristics still in the standard range

Application

SMA launchers are the preferred connection element for varied microwave circuits, including hermetically sealed designs. The SMA line covers a huge variety of applications such as Test+Measurement, mobile communications, avionics, etc.

Applicable Standard

MIL-C-39012;
CECC 22110;
IEC 60169-15.
