Home > Electrical & Electronics > Connector & Terminals > Wire to Wire Connector > Din Type Female RF Connectors

Din Type Female RF Connectors

Name: Din Type Female RF Connectors
Brand: twinlink
SKU: 131143159
Availability: InStock

Din Type Female RF Connectors thumbnail-1

Negotiable MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

twinlink

Model Number:

Custom

Contact Supplier Request Quote Chat Now

Twinlink Communication Technology(Shenzhen) Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name twinlink

Model Number Custom

Type DIN

Application RF

Gender Female

Quick Details

Place of Origin:	Guangdong, China (Mainland)	Brand Name:	Twinlink	Model Number:	7/16
Type:	7/16	Application:	RF	Gender:	Male
frequency range:	0~7.5GHz	withstanding voltage:	4000v,50Hz(sea level)	insulation resistance:	≥10000mΩ
contact resistance(inner):	≤1.0mΩ	contact resistance(outer):	≤0.5mΩ	RF leakage(1GHz):	≥128dB
IMD:	≥160bBc

Packaging & Delivery

Packaging Details:	Foam,carton,blister,vacuumize
Delivery Detail:	13~15 days

Specifications

1.factory/manufacturer
2.OEM&ODM
3.IEC169-4,ISO9001:2008,ISO14001:2004
4.RoHS compliant

Specification

characteristic Impedance 50Ω

frequency Range 0-7.5GHz

withstanding voltage ≥4000V,50Hz

working voltage 2500V,50Hz (sea level)

insulation resistance ≥10000mΩ

contact Resistance inner conductor ≤1.0mΩ

outer conductor ≤0.5mΩ

RF leakage(1GHZ) ≥128dB

Three-order intercept ≥160dBc

Performance description

Twinlink 7/16 din male connector 1/2 cable is a kind of thread connecting coaxial connector manufactured according to IEC169-4 and DIN 47223,and it is featured with low power consumption with high transmitting power .That series are most water proof structures,with applications in outdoor facilities,high power transportation lines,especially in prevailing use of the Antenna and cable system of microwave and mobile communication

Material facts

pin conductor brass--gold plated

body brass--ternary alloy (Cu+Zn+Sn)

plug phosphor bronze/beryllium copper--silver plated

crimping sleeve copper-- ternary alloy (Cu+Zn+Sn)

Insulator PTFE / PFA

sealing ring silica rubber

Customization available

Twinlink professional and sophisticated R*D team are ready to spring into action

Certificates

RoHS,ICE169-4,ISO9001:2000

How to order
