4.3-10 Connector Cable Assembly RF Coaxial 4 Hole 4.3-10 Connector

4.3-10 Connector Cable Assembly RF Coaxial 4 Hole 4.3-10 Connector thumbnail-1
4.3-10 Connector Cable Assembly RF Coaxial 4 Hole 4.3-10 Connector photo-1
US$ 0.99 - 1.35 MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Model Number:
4.3-10
Type:
DIN
Contact Supplier Request Quote Chat Now
Twinlink Communication Technology(Shenzhen) Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Model Number 4.3-10
Type DIN
Application RF
Gender Female

4.3-10 Connector Cable Assembly RF Coaxial 4 Hole 4.3-10 Connector



 Features

lWide Frequency Range

lExcellent Coupling Flatness

lHigh Directivity / Isolation

lCavity structure, High power handing

lLow Insertion Loss, Low VSWR



ELECTRICAL DATA
Impedance                                                                  50Ω
Frequency range (for connector interface) DC~6GHz
Dielectric withstanding voltage (at sea level) ≥750-1500V,50Hz (depending on cable)
Working voltage (at sea level) ≥250-500V,50Hz (sea level) / ≥65-125V,50Hz (Height 21000M)
Insulation resistance ≥ 5000 mΩ
Contact resistance Inner conductor: ≤3mΩ
Outer conductor: ≤2.5mΩ
RF leakage(2-3GHZ) Flexible: ≥60dB
Semi-rigid cable: ≥100dB

MECHANICAL DATA
Coupling nut torque 0.8Nm--1.1Nm / 7.1 in.lbs--9.7 in.lbs
Coupling nut retention force ≥270N / 60.7 lbs
Contact captivation axial ≥27N / 6.1 lbs
Durability (matings) ≤500

ENVIRONMENTAL DATA
Temperature range -65°C to +165°C

MATERIAL DATA
Bodies, outer contacts Beryllium copper--Au plating
Stainless steel--Passivation
Brass--Au plated / ternary alloy plating
Phosphor bronze --Au plating
Pin contacts Brass/Beryllium copper--Au plating
Socket contacts Beryllium copper / Phosphor bronze--Au plating
Crimp ferrules Brass--Au plating
Insulator PTFE
Gaskets Silicone rubber



Reference Pictures

4.3-10 Connector Cable Assembly RF Coaxial 4 Hole 4.3-10 Connector4.3-10 Connector Cable Assembly RF Coaxial 4 Hole 4.3-10 Connector4.3-10 Connector Cable Assembly RF Coaxial 4 Hole 4.3-10 Connector4.3-10 Connector Cable Assembly RF Coaxial 4 Hole 4.3-10 Connector





FAQ

1.What is your quality control?

-Quality is our soul and culture.We have 100%strict inspection and testing before shipment.We will return the money to you if there is quality problem.

2.Can you accept small order?

-Yes,small order is available in our company.We support new project of our customers as we know business is always from small to big.

Your sucess is my business.

3.Can I order samples before placing the bulk order?

-Yes,samples is certainly for your test before the bulk order.It is normal process,we always deal with other clients.

However,we will charge for a small amount of deposit in case the investment on new samples.But please donot worry,the sample deposit will refund to you when bulk order fixed.

4.What is the lead time for samples?

-About sample making,it usually takes 7-15days include testing to make sure its excellent.

If urgently,please kindly let us know,we will do our best to work overtime to speed up it.
