SMA M R/A Crimp for RG174/RG316 RF Connector Coaxial Connectors
US$ 0.5 - 1
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Twinlink
Model Number:
SMA
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Low Pim 7/16 Type Coaxial Din Female Male RF Connector 1/2" Superflex Corrugated Cable AssemblyUS$ 1.2 - 1.2MOQ: 500 Pieces -
Low Pim 7/16 Series Din Female Male RF Connector High Quality 1/2" Superflex Corrugated Cable AssemblyUS$ 1.2 - 1.2MOQ: 500 Pieces
-
Low Pim 7/16 Series Coaxial Din Female Male RF Connector High Quality 1/2" Superflex Corrugated CableUS$ 1.2 - 1.2MOQ: 500 Pieces
-
Low Pim 7/16 Din Female Male RF Connector 1/2" Superflex Corrugated CableUS$ 1.2 - 1.2MOQ: 500 Pieces
-
Low Pim 7/16 Type Din Female RF Connector High Quality 1/2" Superflex Corrugated CableUS$ 1.2 - 1.2MOQ: 500 Pieces
Place of Origin
Guangdong, China
Brand Name
Twinlink
Model Number
SMA
Type
SMA
Application
RF
Gender
Male
SMA M R/A Crimp for RG174/RG316 RF connector coaxial connectors
| Performance description | |
| ODM SMA RF connector is a type of small size,wide frequency,excellect mechanical naturehigh reliability,etc.All meet with the stand of MIL-C-39012, IEC169-15 & CECC22110.With Twinlink unique reasonable structure and sound performance | |
| Electrical specification | |
| Characteristic Impedance: | 50Ω |
| Frequency Range: | Flexible: 0-18GHz |
| Withstand Voltage: | 750-1500V,50Hz |
| Working Voltage: | 250-500V,50Hz(see level) |
| Insulation Resistance: | ≥5000mΩ |
| Contact Resistance: | Inner conductor: ≤3mΩ |
| Outer conductor: ≤2.5mΩ | |
| RF Leakage(1GHZ): | Flexible: ≥60dB |
| Semi-rigid cable:≥100dB | |
| Mechanical Specification | |
| Pin conductor(Center contact): | Brass/Beryllium copper-Gold plated |
| Body: |
Beryllium copper-Gold plated Stainless steel-passivation Brass-Gold plated/Ternary alloy(Cu+Zn+Sn) Phosphor bronze-Gold plated |
| Plug: | Beryllium copper/Phosphor bronze--Gold plated |
| Crimping suite: | Brass--Gold plated |
| Insulator: | PTFE / PFA |
| Sealing | silica rubber |
