2017 High Quality 4.3-10 Coaxial Male/Female Connector

FOB Price

US$ 0.99 - 2.99 / Piece

500 Pieces(Min. Order)

Port shenzhen

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Model Number	4.3-10
Type	DIN	Application	RF
Gender	Female

Product Description

2017 High Quality 4.3-10 Coaxial Male/Female Connector

Features

lWide Frequency Range

lExcellent Coupling Flatness

lHigh Directivity / Isolation

lCavity structure, High power handing

lLow Insertion Loss, Low VSWR

ELECTRICAL DATA
Impedance	50Ω
Frequency range (for connector interface)	DC~6GHz
Dielectric withstanding voltage (at sea level)	≥750-1500V,50Hz (depending on cable)
Working voltage (at sea level)	≥250-500V,50Hz (sea level) / ≥65-125V,50Hz (Height 21000M)
Insulation resistance	≥ 5000 mΩ
Contact resistance	Inner conductor: ≤3mΩ
Contact resistance	Outer conductor: ≤2.5mΩ
RF leakage(2-3GHZ)	Flexible: ≥60dB
RF leakage(2-3GHZ)	Semi-rigid cable: ≥100dB

MECHANICAL DATA
Coupling nut torque	0.8Nm--1.1Nm / 7.1 in.lbs--9.7 in.lbs
Coupling nut retention force	≥270N / 60.7 lbs
Contact captivation axial	≥27N / 6.1 lbs
Durability (matings)	≤500

ENVIRONMENTAL DATA
Temperature range	-65°C to +165°C

MATERIAL DATA
Bodies, outer contacts	Beryllium copper--Au plating
	Stainless steel--Passivation
	Brass--Au plated / ternary alloy plating
	Phosphor bronze --Au plating
Pin contacts	Brass/Beryllium copper--Au plating
Socket contacts	Beryllium copper / Phosphor bronze--Au plating
Crimp ferrules	Brass--Au plating
Insulator	PTFE
Gaskets	Silicone rubber

Reference Pictures

FAQ

1.What is your quality control?

-Quality is our soul and culture.We have 100%strict inspection and testing before shipment.We will return the money to you if there is quality problem.

2.Can you accept small order?

-Yes,small order is available in our company.We support new project of our customers as we know business is always from small to big.

Your sucess is my business.

3.Can I order samples before placing the bulk order?

-Yes,samples is certainly for your test before the bulk order.It is normal process,we always deal with other clients.

However,we will charge for a small amount of deposit in case the investment on new samples.But please donot worry,the sample deposit will refund to you when bulk order fixed.

4.What is the lead time for samples?

-About sample making,it usually takes 7-15days include testing to make sure its excellent.

If urgently,please kindly let us know,we will do our best to work overtime to speed up it.
