Home > Auto, Motorcycle Parts & Accessories > Car Safety > Car DVR > Kit Dvr 4 Cameras Technology IP Camera 4CH POE NVR CCTV Camera

Kit Dvr 4 Cameras Technology IP Camera 4CH POE NVR CCTV Camera

Kit Dvr 4 Cameras Technology IP Camera 4CH POE NVR CCTV Camera thumbnail-1
Kit Dvr 4 Cameras Technology IP Camera 4CH POE NVR CCTV Camera thumbnail-2
Kit Dvr 4 Cameras Technology IP Camera 4CH POE NVR CCTV Camera thumbnail-3
Kit Dvr 4 Cameras Technology IP Camera 4CH POE NVR CCTV Camera thumbnail-4
Kit Dvr 4 Cameras Technology IP Camera 4CH POE NVR CCTV Camera thumbnail-5
Kit Dvr 4 Cameras Technology IP Camera 4CH POE NVR CCTV Camera thumbnail-6
Kit Dvr 4 Cameras Technology IP Camera 4CH POE NVR CCTV Camera photo-1
Kit Dvr 4 Cameras Technology IP Camera 4CH POE NVR CCTV Camera photo-2
Kit Dvr 4 Cameras Technology IP Camera 4CH POE NVR CCTV Camera photo-3
Kit Dvr 4 Cameras Technology IP Camera 4CH POE NVR CCTV Camera photo-4
Kit Dvr 4 Cameras Technology IP Camera 4CH POE NVR CCTV Camera photo-5
Kit Dvr 4 Cameras Technology IP Camera 4CH POE NVR CCTV Camera photo-6
US$ 200 - 300 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Gaozhi
Model Number:
GZ-KN44-B62
Contact Supplier Request Quote Chat Now
Hunan Gaozhi Science And Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Gaozhi
Model Number GZ-KN44-B62

2016 New Kit dvr 4 cameras Technology IP Camera 4CH POE NVR CCTV Camera

2016 New  Kit dvr 4 cameras Technology IP Camera 4CH POE NVR CCTV Camera

Product Description





Kit dvr 4 cameras Technology IP Camera 4CH POE NVR CCTV Camera



Kit dvr 4 cameras Technology IP Camera 4CH POE NVR CCTV Camera





Kit dvr 4 cameras Technology IP Camera 4CH POE NVR CCTV Camera



  1080P  PoE  IR  Bullet IP Camera

  Model no.:   GZ-IPC-B6206-P

Pictures Kit dvr 4 cameras Technology IP Camera 4CH POE NVR CCTV Camera





Key features

•Chipset GM8136

•1/3" 1080P progressive scan CMOS

• H.264 High profile encoding
• Max. 25fps@1080P
• Supports IR-CUT filter switch to achieve day and night monitoring
• Metal housing, Ingress protection IP66
• Max. IR LEDs distance 30m
• Onvif V2.1 protocol
• Built-in PoE for easy installation


Camera Image Sensor 1/3" 1080P CMOS
Effective Pixels 1920 (H)x1080(V)
Min. Illumination Color: 0. 05LUX/F1.8, B/W: 0Lux (IR on)
S/N  Ratio >50dB
Backlight Compensation BLC
WDR Digital WDR
Noise Reduction 3D DNR
Gain Control Auto/Manual
Day/Night Auto(ICR) / Color / B/W
White Balance Auto
Electronic Shutter Speed Auto/Manual 1/50~1/10000
IR distance IR distance 30 Meters
Lens Focal Length 6mm Lens
Max Aperture F1.8
Focus control Fixed
Angle of View 53°@6mm
Video Video Compression H.264 High Profile / JPEG Snapshot
Resolution Main Stream:1080P(1920*1080)
Sub Stream: 352*288
Video Bitrates 1024Kbps ~ 6144Kbps
Video Frame Rate 25fps@1080P
Audio  Compression ADPCM
Interface embedded mic in
Network Ethernet RJ-45 (10/100Base-T)
Wi-Fi Option
Network Protocol IPv4, HTTP, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP,
SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Cloud
Network Preview Web browser view, including IE,Chrome,Firefox
Smart Phone Supports iPhone,iPad, Android phone,pad,Windows Mobile phone.
Compatibility Onvif V2.1
Max. User Access 12 Users
General Power Supply DC12V   & PoE
Power Consumption <8W
Working Environment -10℃~+55℃(14°F~131°F),10%~90%
Ingress Protection IP66
Dimensions Φ65 x 188mm
Weight 440g



Kit dvr 4 cameras Technology IP Camera 4CH POE NVR CCTV Camera

     4CH POE NVR Model no.:  GZ-NVR-6004           Main Chip: Hisilicon 3520D
Pictures Kit dvr 4 cameras Technology IP Camera 4CH POE NVR CCTV Camera
Key features


• 4CH 1080P/720P IP camera input;
• 1/4CH playback;
•embeded 4 PoE Network ports;
• Supports dual stream;
• Supports VGA (Maximum HD 1080p) , HDMI (Maximum HD 1080p) output;
• 2 USB2.0 ports, 1SATA 3.0 HDD port(up to 4000G);
•Supports smart phone real time remotely monitoring, such as iPhone,Android;
• Provide IE Activex,CMS,StreamView APP
• Support P2P
System GUI 16-bit True Color
Operating System  Embedded Linux OS
Password security Multi-level users management, 1 Admin + 19 Users
A/V Input Video Input  IP Camera x4   POE
Audio Input NO
A/V Output Decoding resolution 1080P/720P
VGA output 1024*768,1280*720,1280*800,1280*1024,1440*900,1920*1080P (1080P)
HDMI output 1024*768,1280*720,1280*800,1280*1024,1440*900,1920*1080P (1080P)
Audio output NO
Playback resolution 1080P/720P
Synchronous playback 4CH(PAL:100FPS playback  NTSC:80FPS playback)
HDD SATA Devices  1 x SATA HDD
Maximum capacity 4TB
External HDD NO
External Interface USB Connector 2 x USB2.0
Serial Interface NO
2 way audio (voice talk) NO
Alarm input/output Optional
Network Interface  RJ 45,10M/100 M Ethernet, 4 Network ports for IP camera, 1 Giga network port for LAN/WAN
Network Network protocol TCP/IP, SMTP, HTTP, DHCP, PPPoE, NTP, DDNS,UPnP,FTP,RTSP,Onvif,P2P
Mobile Device iPhone, iPad,Android Phone, Android Pad
System Upgrade Supports USB update
Remote Software StreamView APP, IE Browser,Google Chrome Browser,Firefox Browser
General Power Supply Input 100~240V, 48V 2A
Consumption  <10W  without HDD&PoE
Working temperature -10℃~+55℃(14°F~131°F)
Working humidity 10%~90%
Dimension ( mm ) 260(W) x 41(H) x 230(D)
Weight ( w/o HDD/DVD±RW ) 2.0 kg





What's included



Kit dvr 4 cameras Technology IP Camera 4CH POE NVR CCTV Camera



                                                                        BOM For 4CH 2MP NVR kit
NO. Items Specification Quantity 1. Economy
kit  		2. Standard kit 3.super
 kit
1 NVR 2megapixel 4ch POE NVR 1 √ √ √
2 Original color box of NVR with foam 1 √ √ √
3 Adapter of NVR 12V-2A 1 √ √ √
4 Dryer bags   1 √ √ √
5 Software CD 3.5" 1 √ √ √
6 Remote Control with battery   1 √ √ √
7 USB Mouse(Red light) USB Mouse with red light 1 √ √ √
8 E-sata   1 √ √ √
9 Ethernet Cable 3.5ft / 1m 1 √ √ √
10 Ethernet Cable 20m 4 √ √ √
11 HDMI cable 6.5ft / 2m 1   √ √
12 Hard Disk   1     √
13 2MP Bullet IP Camera
 (Model:IPC-B6206-P) 		2megapixel POE Bullet camera 4 √ √ √
14 Original color box of Camera 1 package with 4 cameras 4 √ √ √
15 Outer box   1 √ √ √
16 Screw installation package   4 √ √ √



Company Information

 Kit dvr 4 cameras Technology IP Camera 4CH POE NVR CCTV CameraKit dvr 4 cameras Technology IP Camera 4CH POE NVR CCTV Camera

FAQ



 1.Compatibility



IP Cameras Support onvif 2.1,seamless integrated with different brand NVR.

NVR can only support our Ip camera .



2.Warranty



 2-years free repair Warranty. For the confirmed defective products , will send free replacement in the next shipment .



3.ODM Service



Strong RD team from HUAWEI with 11 years experience, provide satisfactory ODM service. You can have your OWN logo or start-up screen for free if quantity meet the MOQ. Same to Customized package .



4.APP remote control

Both Support mobile app named Streamview ,and pc software named Smart Client for remote control.



5.Surveillance Distance



A. 2.8 mm lens : Less than 10m

B. 3.6mm lens :10m—20m

C. 6mm lens : 30m—50 m

(We have 2.8—12 mm auto-Focus camera for long distance & special condition.





Related products



                                                         Related products
                                         More details of IP camera and NVR , please click below pictures



                 Kit dvr 4 cameras Technology IP Camera 4CH POE NVR CCTV Camera             Kit dvr 4 cameras Technology IP Camera 4CH POE NVR CCTV Camera
                         1080P IP camera (GZ-IPC-B6206-P)
               1080p/2MP 4CH NVR GZ-NVR-6004)





Kit dvr 4 cameras Technology IP Camera 4CH POE NVR CCTV Camera
