1080P/2MP PoE IR Onvif V2.1 Dome Network Camera
1080P/2MP PoE IR Onvif V2.1 Dome Network Camera
* 1/3" 1080P progressive scan CMOS
* H.264 High profile encoding
* Max. 25fps@1080P
* Supports IR-CUT filter switch to achieve day and night monitoring
* Metal housing, Ingress protection IP66
* Max. IR LEDs distance 20m
* Onvif V2.1 protocol
* Built-in PoE for easy installation
| Specification | |||
| Camera | Image Sensor | 1/3" 1080P CMOS | |
| Effective Pixels | 1920 (H)x1080(V) | ||
| Min. Illumination | Color: 0. 05LUX/F1.8, B/W: 0Lux (IR on) | ||
| S/N Ratio | >50dB | ||
| Backlight Compensation | BLC | ||
| WDR | Digital WDR | ||
| Noise Reduction | 3D DNR | ||
| Gain Control | Auto/Manual | ||
| Day/Night | Auto(ICR) / Color / B/W | ||
| White Balance | Auto | ||
| Electronic Shutter Speed | Auto/Manual 1/50~1/10000 | ||
| IR distance | IR distance 20 Meters | ||
| Lens | Focal Length | 3.6mm Lens | |
| Max Aperture | F1.8 | ||
| Focus control | Fixed | ||
| Angle of View | 75°@3.6mm | ||
| Video | Video Compression | H.264 High Profile / JPEG Snapshot | |
| Resolution | Main Stream:1080P(1920*1080) Sub Stream: 352*288 |
||
| Video Bitrates | 1024Kbps ~ 6144Kbps | ||
| Video Frame Rate | 25 fps@1080P | ||
| Audio | Compression | ADPCM | |
| Interface | embedded mic in | ||
| Network | Ethernet | RJ-45 (10/100Base-T) | |
| Wi-Fi | Option | ||
| Network Protocol | IPv4, HTTP, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Cloud | ||
| Network Preview | Web browser view, including IE,Chrome,Firefox | ||
| Smart Phone | Supports iPhone,iPad, Android phone,pad,Windows Mobile phone. | ||
| Compatibility | Onvif V2.1 | ||
| Max. User Access | 12 Users | ||
| General | Power Supply | DC12V & PoE | |
| Power Consumption | <8W | ||
| Working Environment | -10℃~+55℃(14°F~131°F),10%~90% | ||
| Ingress Protection | IP66 | ||
| Dimensions | Φ120 *77mm | ||
| Weight | 460g | ||
1. Compatibility
IP Cameras Support onvif 2.1,seamless integrated with different brand NVR.
NVR can only support our Ip camera .
2.Warranty
2years free repair Warranty. For the confirmed defective products , will send free replacement in the
next shipment .
3.ODM Service
Strong RD team from HUAWEI with 11 years experience, provide satisfactory ODM service. You can have your OWN logo or start-up screen for free if quantity meet the MOQ. Same to Customized package .
4.APP remote control
Both Support mobile app named Streamview ,and pc software named Smart Client for remote control.
5.Surveillance Distance
A. 2.8 mm lens : Less than 10m
B. 3.6mm lens :10m—20m
C. 6mm lens : 30m—50 m
(We have 2.8—12 mm auto-Focus camera for long distance & special condition. )
| NEW ARRIVAL!! |
| More IP camera optional, click here to view more |
| IP camera and NVR Kits , click here to view more |
| |
|
|
| 2MP domePOE IP camera | 1080P/2MP bullet POE IP camera | 4MP varifocal Dome IP camera |
| |
|
|
| 4MP Dome IP camera | 4MP Bullet IP camera | 4MP varifocal Bullet IP camera |
| |
|
|
| 4MP Varifocal PTZ IP camera | 4MP Bullet IP camera with 16G sd card | 4MP Bullet IP camera |
