cutting tools inserts en carbide
50 Years carbide milling cutting tools inserts
Contacting Now for Free Samples
MACFSSC Principle for Inserts Selection
It is particular important for the selection of cnc machine tools. Due to the various brands and models of machine tools in the market, are you troubled by choosing the right ones. Selecting suitable tools can improve machining precision, reduce the defective goods, cost of tools and extend the service life of cutters.
And Here comes the MACFSSC Principle in choosing inserts:
Tool selection is very complex, so, free consulting immediately to Datan professional tool engineer......
Mail: slash(at)
Skype: slashchen007
Tell: +86 159 6241 0804
Geometry Features for price of cutting tools inserts:
1. NNZ Chip breaker: Flat chip breaker
Medium cutting for general material.
2. NNZ Chip breaker: Medium milling.
For general use in most materials. Most applications general purpose milling.
Medium operations to light roughing. Medium depth of cuts and feed rate.
Grade Application of cutting tools inserts:
TPKN, Triangle 60°, without Hole
| Ordering Code | Dimensions(mm) | ||||
| L | D | S | θ | bs | |
| TPKN1603PDL | 16.5 | 9.525 | 3.18 | 30° | 1.3 |
| TPKN1603PDTL | 16.5 | 9.525 | 3.18 | 30° | 0.8 |
| TPKN1603PDR | 16.5 | 9.525 | 3.18 | 30° | 1.3 |
| TPKN1603PDTR | 16.5 | 9.525 | 3.18 | 30° | 1.3 |
| TPKN2204PDL | 22 | 12.7 | 4.76 | 30° | 1.4 |
| TPKN2204PDTL | 22 | 12.7 | 4.76 | 30° | 1.4 |
| TPKN2204PDR | 22 | 12.7 | 4.76 | 30° | 1.4 |
| TPKN2204PDTR | 22 | 12.7 | 4.76 | 30° | 1.4 |
Two Simple Steps of Carbide Inserts Selection
Step 1, According to shaps of Insert——
Pls click the words below for checking
Square 90° Hexagon 120° Octagon 135°
Triangle 60° Round Parellelogram 85°
Rhombic 80°
Step 2, According to Grades of Carbide Insert——
Pls click the below words for checking
NNZ medium cutting RM heavy milling for XXR heavy milling for
for general material Stainless steel general material
High Cost Effective, With Better Price, Why US!
- Our tool performance can up to Japan and South Korea level, some even to Europe level;
- With the same performance, our price is much lower than high-end brand;
- 50 Years experience that can provide you with highly efficient machining program;
- Offering professional guidence in cutting tool choosing;
- One-stop sourcing of cutting tool;
- Chinese most authoritative cnc cutting tool web for tool choosing, the web is highly regarded by industry association.
320 Workers, 26000 square meters nondust workshop, 50 years of experience, 20 years in market, ISO &CE certificated, superior supplier of YAMAHA, 3M, BOSCH, EMKA, VESUVIUS and VOLKSWAGEN, this is how we keep superior quality and competitive offers for global valued customers.
Datan's mission is to keep customer first in our mind under any circumstance, create and quickly provide excellent value to customers; Providing customers with unique products and services in the board field of material cutting. Welcome your any advice and question for 50 Years carbide milling cutting tools inserts!
And Pls Send Enquires Now for cutting tools inserts!
