Specifications
Y5-47 boiler centrifugal draught fan1.have stock
2.high qualiy
3.good after service
4.delivery:7
Y5-47 boiler centrifugal draught fan
Specification:
| Model(No.) | Power(kw) | Speed(r/min) | Volume Flow( m³/h) | Total Pressure(Pa) |
| 4c | 5.5 | 3550 | 2932~5564 | 2221~1501 |
| 4 | 3150 | 2602~4937 | 1746~1180 | |
| 3 | 2800 | 2313~4388 | 1377~932 | |
| 2.2 | 2500 | 2065~3918 | 1097~742 | |
| 5c | 11 | 3150 | 5304~9851 | 2819~1913 |
| 7.5 | 2800 | 4715~8757 | 2223~1509 | |
| 5.5 | 2500 | 4210~7818 | 1769~1202 | |
| 4 | 2240 | 3772~7005 | 1419~964 | |
| 6.3c | 22 | 2800 | 9432~17516 | 3545~2403 |
| 15 | 2500 | 8421~15639 | 2819~1533 | |
| 11 | 2240 | 7546~14013 | 1798~1221 | |
| 7.5 | 2000 | 6737~12511 | 3323~2253 | |
| 8c | 30 | 2000 | 13794~25619 | 2686~1823 |
| 22 | 1800 | 12415~23057 | 2118~1438 | |
| 15 | 1600 | 11035~20495 | 1619~1100 | |
| 11 | 1400 | 9656~17933 | 4483~2958 |
Working Principle:
Through motor works transmission part so as to impeller to rotate at a high speed. Rotating mechanical energy is converted to gas pressure energy and kinetic energy, and transport the air out through machine frame.
Function:
Y5-47 CENTRIFUGAL FAN with high efficiency, low noise, large wind characteristics and stainless steel material which has anti-corrosion effect. Boiler fan is for variety fuel and equip with dust removal device, which is designed for 0.2~2ton/hr industrial burner or living burner. The transmission of air temperature don’t exceed 250°C. Boiler fan makes of single inhalation, there are No.3.15~No 12.5 type and many others types. Boiler fan has two forms as left rotation and right rotation. Look squarely at fan from transmission part, impeller rotates as clockwise called right rotation fan, with” right” representation; impeller rotates as counter-clockwise called left rotation fan, with “left” representation. Fan exit position express with frame exit angle. “Left” & “right” total have four kinds angles as 0°,90°,180°270°.
About us:
We are a professional manfuacturer in China, rubber processing machines such as Rubber Prebreaker Machines, Rubber Shredder Machines, Twin Helix Breaking & Extruding Washing Machines, Rubber Cutter Machines, Rubber Cleaning Machines, and Belt Conveyer Machines , which mainly produce the natural rubber processing equipment to make the natural rubber into TSR, SMR, SCR, SIR, RSS rubber.
What's more ,and according to customers' request, we did design some new rubber machine and improve the rubber machine feature, what the other factories' machine do not have and hard compare with ours.
Please tell us ur requirement of the line if you need, so that we could design a suitable rubber production line to you.
the site of our factory:
