Home > Manufacturing & Processing Machinery > Woodworking Machinery > Wood Based Panel Machine > Plywood Press A Hot Press Lamination Press

Plywood Press A Hot Press Lamination Press

Plywood Press A Hot Press Lamination Press thumbnail-1
Plywood Press A Hot Press Lamination Press photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Hot Press Machine
Place of Origin:
Jiangsu, China
Contact Supplier Request Quote Chat Now
Suzhou Xinxieli Machine Manufacturing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Hot Press Machine
Place of Origin Jiangsu, China
Brand Name Xinxieli
Model Number XXL-11000-4X8
Voltage 380V
Certification ISO CE
Warranty LIFELONG
After-sales Service Provided Engineers available to service machinery overseas

plywood press A hot press Lamination press

XXL Hydraulic Press is mainly appiled in the lamination of furniture decorative board and laminate flooring.We provide customers with various lamination lines according to their requirement. At present three are basic types:

XXl-E economical type overlaying production line

XXL-S standard type overlaying production line

XXL-A automatic type overlaying production line



1. Finished product size               1300×2500mm

2. Pressing cycle                 According to technological requirement

3. Total power                               ~46.5kW

4. Thermal consumption                25×104 kcal/h

5. Compressed air consumption    ~0.6m3/min  0.6Mpa

6. Total pressure                          11000kN

7. Specific pressure                       34kg/cm2

8. Hot platen size                       1400×2600mm

9. Daylight opening                      300mm

10.Main oil cylinder(diameter×stroke)  300×300mm   6 units

11. Lifting cylinder(diameter×stroke)   90×300mm    2units

12. Oil pressure of hydraulic system     ≤25Mpa

13. Temperature of hot platen              ≤200°C

14. Heating medium                             Thermal oil or steam

15. Feeding speed                          20~80m/min (adjustable)

16. Vacuum conveyor speed           60~80m/min (adjustable)

17. Control mode                          Man-machine interface + PLC

18. Blowing rate of dust exhauster   ~3000m3/h(User prepares Dust exhauster)

19. Total net weight                           ~ 65000kg

20. Overall dimension(L×W×H)         ~32000×4800×4100mm
