Cheaper Sprinkler CCTV Camera/Mini Hidden Camera

Name: Cheaper Sprinkler CCTV Camera/Mini Hidden Camera
Brand: VIVIEYE
SKU: 130960189
Availability: InStock

US$ 26.5 - 28 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

VIVIEYE

Model Number:

NCL-25H

Shenzhen Newsurway Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

ShenZhen /HONGKONG

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name VIVIEYE

Model Number NCL-25H

Type Analog Camera

Style Hidden Camera

Sensor CCD

Technology Pinhole

Special Features Other, Hidden camera

Specifications

Mini Sprinkler CCTV Camera
1.Water Spray housing
2.1/3'' SONY Super HAD II CCD 420TVL
3.Pinhole 3.7 mm core lens/DC12V

Mini Sprinkler CCTV Camera

1.Water Spray housing
2.1/3'' SONY Super HAD II CCD 420TVL
3.Pinhole 3.7 mm core lens/DC12V

4. Water spay housing

Specification

Model No.	NCL-25H	NCL-25K
Camera Type	Color Fire Sprinkler Camera
Image Sensor	1/3 Inch SONY SuperHAD CCD	1/4 Inch SONY SuperHAD CCD
Effective Pixels	PAL:500(H) x 582(V) 290K NTSC:510(H) x 492(V) 250K
Sensing Area	4.9mm x 3.7mm	3.6mm x 2.7mm
Signal System	PAL /NTSC
Horizontal Resolution	420 TV Lines
Min. Illumination	0.5 Lux/F1.2	0.8 Lux/F1.2
Lens Mount	Pinhole lens 3.7mm
S/N Ratio	More Than 48dB (AGC Off)
Electronic Shutter	1/50(1/60) ~ 1/10,000 Sec.
White Balance	Auto
AGC	Auto
I/O Connector	Power : DC Power Jack , Video Output : BNC
Video Output Level	1.0 Vp-p (75 Ohms, composite)
Supplied Voltage	DC12V Voltage
Power Consumption	Less than 130mA
Dimensions	83 x68mm
Weight	Approx. 0.35kg
