Help CenterHastelloyC-276 Cold Drawn Pipe
US$ 10 - 30
MOQ: 300 Kilograms
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Zhonghai
Model Number:
HastelloyC-276
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
HastelloyC-276 Cold Rolled StripUS$ 10 - 30MOQ: 300 Kilograms -
Incoloy800H Forged Square BarUS$ 10 - 30MOQ: 300 Kilograms
-
Incoloy800H Hot Rolled CakeUS$ 10 - 30MOQ: 300 Kilograms
-
Incoloy800H Hot Rolled RingUS$ 10 - 30MOQ: 300 Kilograms
-
Incoloy800H Hot Rolled SleeveUS$ 10 - 30MOQ: 300 Kilograms
Place of Origin
Jiangsu, China
Brand Name
Zhonghai
Model Number
HastelloyC-276
Application
pulp and paper making industry, acidic gas environments,
Shape
round
Material
nickel-based alloy
Dimensions
range from 6*0.6mm to 200*20mm
Chemical Composition
Ni-Cr-Fe
Specifications
High electrical conductivity, excellent corrosion resistance, and good thermal, electrical and magnetostrictive properties.
Hastelloy C-276 Chemical composition
Hastelloy C-276 Physical properties:
Hastelloy C-276 Alloy m inimum mechanical properties in the room temperature
7.Manufacture and processing of impure phosphoric acid.
Alloy |
% |
Ni |
Cr |
Mo |
Fe |
W |
Co |
C |
Mn |
Si |
V |
P |
S |
C |
Min. |
balance |
14.5 |
15 |
4 |
3 |
|||||||
Max. |
16.5 |
17 |
7 |
4.5 |
2.5 |
0.08 |
1 |
1 |
0.35 |
0.04 |
0.03 |
||
C276 |
Min. |
balance |
14.5 |
15 |
4 |
3 |
|||||||
Max. |
16.5 |
17 |
7 |
4.5 |
2.5 |
0.01 |
1 |
0.08 |
0.35 |
0.04 |
0.03 |
Hastelloy C-276 Physical properties:
Density |
8.9 g/cm³ |
Melting point |
1325-1370 ℃ |
Hastelloy C-276 Alloy m inimum mechanical properties in the room temperature
Alloy state |
Tensile strength Rm N/mm² |
Yield strength
R P0. 2N/mm²
|
Elongation A 5 % |
C /C276 |
690 |
283 |
40 |
Characteristic as below
1.Excellent corrosion resistance to most of corrosion media in oxidation and reduction environments.
2.Excellent resist pitting, crevice corrosion and stress corrosion cracking performance.
Hastelloy C-276 Metallurgical structure
C276 is face-centered cubic lattice structure.
C276 is face-centered cubic lattice structure.
Hastelloy C-276 Corrosion resistance
C276 alloy suit for many kinds of chemical process industry which contain the oxidizing medium and reductant. High molybdenum and chromium content make it can resist the chloride corrosion, and tungsten make it corrosion resistance better.C276 is one of a few material that can resist the corrosion of most chlorine, hypochlorite and chlorine dioxide, this alloy have prominent corrosion resistance to high concentration chlorate( iron chloride and copper chloride).
C276 alloy suit for many kinds of chemical process industry which contain the oxidizing medium and reductant. High molybdenum and chromium content make it can resist the chloride corrosion, and tungsten make it corrosion resistance better.C276 is one of a few material that can resist the corrosion of most chlorine, hypochlorite and chlorine dioxide, this alloy have prominent corrosion resistance to high concentration chlorate( iron chloride and copper chloride).
Hastelloy C-276 Application field:
C276 is widely used in the chemical field and petrifaction field, such as the element of chloride organic and catalyze system.This material especially suit for high temperature environment, impure inorganic acid and organic acid (such as formic acid and acetic acid), sea-water corrosion environment.
C276 is widely used in the chemical field and petrifaction field, such as the element of chloride organic and catalyze system.This material especially suit for high temperature environment, impure inorganic acid and organic acid (such as formic acid and acetic acid), sea-water corrosion environment.
Hastelloy C-276 Other application field:
1. The digester and bleacher in the use of paper pulp and paper making industry.
2.Absorption tower, re-heater and fan in the FGD system.
3. The equipment and parts in the use of acidic gas environments.
4. Acetic acid and anhydride reaction generator
5. Sulfur acid cooling
6.MDI5. Sulfur acid cooling
7.Manufacture and processing of impure phosphoric acid.
