Smart wireless ip wifi doorbell camera
Product Categories | ||||
| Video DoorPhone | TVI Camera | AHD DVR | AHD Camera | IP Camera |
| Standalone DVR | IR Waterproof Camera | NVR-Network Video Recorder | Dome Camera | |
| Wireless Camera | High Speed Dome | CMOS Camera | Car Camera | Conceal Camera |
| Balun | Mini Camera | peripheral products | Box Camera | HD SDI Products |
- wifi doorbell camera
- password authority management,white list,white list set
- wireless,reticle both are OK
- support IPhone,Android 2.2 above mobile phone long-distance answer doorbell andunlocking
- support motion detection,give an alarm message sinkas well as long-distance surveillance
- and support long-distance photograph,picture recording
Technical Specification
Item: IDB-01 | ||
video |
compress mode |
MJPG |
Signal System |
CMOS Sensor |
|
frame rate |
25/30fps |
|
|
VGA : 640x480Pixels |
|
image adjustment |
automatic white balance,backlight compensation |
|
Lens |
2.5mm lianr |
|
night vision |
infrared LED |
5 IR LEDs, Night visibility up to 5meters |
network |
network interface |
RJ-45 10/100Mb self-adaption ethernet interface |
networking protocol |
Support TCP/IP,HTTP,ICMP,DHCP,FTP,SMTP,PPPoE and so on |
|
Data Rate |
WIFI,802.11b: 11Mbps(Max.), 802.11g: 54Mbps(Max.) 802.11n: 150Mbps(Max.) |
|
support user number |
8 person |
|
support IP Add |
static state IP Add,dynamic IP Add,PPPOE dial |
|
other |
appearance,operating environment |
metal,anti-explosion,outdoor |
Power Supply |
DC12V 1A |
|
|
Operate Temper, Storage Humidity |
–25~70℃ 95% RH |
|
Dimension |
fuselage Size: 116x86x25(mm)(LxWxH) Color Box Size:: 200x135x50(mm(LxWxH) |
|
Weight |
Net Weight:206g ( accessories included) packing box Weight:278g Gross Weight:484g(remark:in kind be as the criterion) |
|
outer packing |
20PCS/box |
|
accessories |
AC adapter specification folder install screw |
|
give an alarm |
alarm detecting |
motion detection,detection sensitivity set |
immediately give an alarm |
immediately give an alarm to mobile phone |
|
system requirement |
system |
Android 2.2 above versions IOS system iphone, Android |
- NEWSURWAY CCTV, a professional CCTV Camera and DVR manufacturer for about 14 years in China
- We supply CCTV AHD Cameras and DVRs, IP Cameras and NVR, AHD DVR Kits, and NVR Kits.
- NEWSURWAY regard client as our god, regard service as our life, regard innovation as our soul.With this in our heart, NEWSURWAY will get win-win situation with you together all the time.
- Choose NEWSURWAY will be your correct choice for CCTV Supplier in China.
- OEM, ODM, Neutral Packing are welcome.
- DHL, Fedex, EMS, Air Freight, Special Lines, Sea Shipment terms are optional.
NEWSURWAY attends International Exhibitions every year,such as ISC West show in Germany Essen, USA, EXPOSEC in brazil, Crocus Exhibition Center Moscow in Russia, Intersec in Dubai, IFSEC in UK, EXPO in Mexico etc.
- Factory: More than 4500 square meters, available for OEM& ODM
- Lead time: 3-7 working days after payment received
- Authentication: CE, FCC, SGS & ROHS
- T/T, L/C, Western Union, Paypal
- Guarantee: 1-2 years
- QC inspection: Strict 5 steps before shipment
- Products Innovation: 10-20 New items per month.
After-sales Service:
- All our products will be checked in production and before delivery.
- Please contact us if any problem, we will respond within 24 hours.
1, What is the output video format?
To the output video,the format is H.264.
2, Does the module delivered include the mount?
yes,the module is included with the mount.
3, Can the camera be set to FPS below 25?
That is possible,you can choose the fps 1-25 fps.
To 20CM-1M,that is Easy to for our Camera,Our Camera use Board lens 3.6mm/F2.0 and 2.8-12mm Manual Zoom (2M Pixels),that distance object is easy to get.
5, We would like to get the image with FOV (Field of View) around 70 degrees. Could the lens & sensor be capable of providing this FOV?
To Board lens 3.6mm the effective FOV is 75.7°, And 2.8-12mm Manual Zoom (2M Pixels),the Effective FOV is 89.9°
6, We will use only 1 meter of RJ45 cable to transfer the data. What is the minimum delay that the camera could provide?
To the RJ45 Cable,Our Normal IP Camera is not added that port,but the IP High speed dome Camera have this Function,You can check my list first,to see which products suits your demands.
7, Does the camera have Auto White Balance (AWB) option? Can we turn it off, since it makes us harder to process the image ?
Yes,our Camera have the AWB option,but we not supported to turn it off,as this the default setting.
8, Can you provide customer's logo on the product? What is the price of it, besides the price of the camera module?
That is possible to print your custmer's logo in the products,we need to added 20usd for openning the logo module(Only charge one time),each camera module added 0.5USD.
9, Can IR LED be switched to white LEDs or simply be not installed in the camera? Will the price change in this situation and how much?
The IR LED revised with the White LED,that need to choose the camera housing,and if not install in the Camera,that all depends on the housing,Pls let me know the Camera housing that you are interested.
