High Quality 16 Channel h.264 Network Security CCTV DVR AHD DVR System
Key words: AHD DVR
Main features:
- Ø HD iDVR Three in one: DVR / HVR / NVR features 3-in-1, multi-mode input, support four analog video encoding, support for high-definition video mixing analog inputs + network support pure HD network video input.
- Ø Step on the Internet:With cloud service, easy to achieve a variety of network penetrations ,one step to remote monitoring, getting rid of various complicated network settings, easy and simple to operate.
- Ø Compression algorithm ideal:H.264 High Profile compression algorithm,30% decrease of stream due to advanced space-time filtering technology.
- Ø Playback quality: Supports full real-time encoding video, full real-time playback of multi-channel synchronous decoding.
- Ø Main and Sub Stream:Main stream and Sub-stream encoding. Main stream for local storage, ensure image quality; Sub-stream for real-time network transmission, easy to solve bandwidth bottleneck problem.
- Ø Mobile monitor: Support various mobile monitoring(iPhone, Windows Mobile, BlackBerry, Symbian, Android).
- Ø Display: support VGA, HDMI HD output.
- Ø Operation interface:Similar to Windows operating style, easy to get started with powerful mouse right-click function.
- Ø Network:Powerful network services (support DHCP, PPPOE, FTP, DNS, DDNS, EMAIL,IP searches etc.) And perfect support (WEB, Client, SDK), easy to achieve interoperability.
- Ø Browsers:Support IE,Chrome,Firefox,Safari browsers.
- Ø Remote Access:3322 (Greek network), dyndns, oray (peanut shells), myq-see and other Domain Name Services are also provided.
- Ø Differentiation: Boot screen free replacement, more than twenty languages, over 10 sets of GUI interface, ten kinds of remote control, which make our products different from others.
- Ø Others:With unique black box technology, the whole process can be monitored, which greatly reduces maintenance costs.
Technical specification:
|
Model |
AVR-6316FM |
System |
Main processor |
Hi3531 |
Video |
Video compression |
H.264(High Profile) |
Encode capacity |
16*720P |
|
Decode capacity |
1*720P |
|
|
Multi-mode input |
Pure analog: 16*720P/8*720P/16*AHD-L pure network: 1*1080P+8*720P/4*1080P/20*960H analog + network: 4*720P (analog) + 4*720P(network) |
|
Audio |
Audio compression |
G.711A |
Intercom |
support |
|
Record & playback |
Record mode |
manual>alarm>motion detection>timing |
Playback |
4ch: 1ch real time+3ch non-real time |
|
Storage & backup |
Space occupation |
Video:720P 20G / day* channel; 960H 12 ~ 20G / day * channel; Audio: 691.2M / day * channel |
Backup mode |
Network, U-disk, USB burner, SATA burner |
|
Interface |
Video input |
16ch BNC |
Video output |
1ch VGA, 1ch HDMI |
|
Audio input |
2ch RCA |
|
Audio output |
1ch RCA |
|
Alarm input |
0 |
|
Alarm output |
0 |
|
Network interface |
RJ45 10M/100M |
|
PTZ control |
1*RS485, Support multiple PTZ protocols |
|
USB |
2* USB 2.0 |
|
HDD |
2*SATA port (Max 4TB/per) |
|
Wireless |
3G, WIFI (extension via USB) |
|
other |
Power supply |
12V2A or 12V/4A |
The specification is subject to change without notice
