CCTV AHD TVI CVBS IP 4 in 1 Hybrid DVR Recorder for Security System

CCTV AHD TVI CVBS IP 4 in 1 Hybrid DVR Recorder for Security System photo-1
CCTV AHD TVI CVBS IP 4 in 1 Hybrid DVR Recorder for Security System photo-2
CCTV AHD TVI CVBS IP 4 in 1 Hybrid DVR Recorder for Security System photo-3
CCTV AHD TVI CVBS IP 4 in 1 Hybrid DVR Recorder for Security System photo-4
CCTV AHD TVI CVBS IP 4 in 1 Hybrid DVR Recorder for Security System photo-5
US$ 18 - 18.8 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
OEM
Model Number:
AVR-6804AH
Payment & Shipping
Payment Methods:
Port of Shipment:
guangzhou/shenzhen/hongkong
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name OEM
Model Number AVR-6804AH

CCTV AHD TVI CVBS IP 4 in 1 Hybrid DVR recorder for  security system



AVR-6804AH



Product Description



•H.264 Video compression
•AHD/NVR/DVR Three-in-one
•Support multi-mode switch
AHD/TVI: 4CH*1080H
AHD+Analog: 2CH*1080H+2CH*960H
IPC: 4CH*720P
Synchronous palyback:D1/CIF/720P/960P

AHD DVR



Specification:

MODEL AVR-6804AH

Video/Audio input

Video compression H.264
Analog video input 4PCS BNC Port(Level: 1.0Vp-p, impedance : 75Ω)
Audio compression ADPCM
Audio input 4PCS RCA Port(Level : 2.0Vp-p, impedance : 1kΩ)
Two-way audio input 1PCS RCA Port( line level , impedance : 1kΩ)
Video/Audio output
Multi-mode switch AHD/TVI: 4CH*1080H
AHD+Analog: 2CH*1080H+2CH*960H
Analog: 4CH*960H
IPC: 4CH*720P
HDMI/VGA output 1024x768,1280*720,1280x1024
CVBS output 1PCS BNC Port(Level: 1.0Vp-p, impedance : 75Ω)
Encording resolution D1/CIF/720P/960P
Frame rate NTSC:1~30FPS/S;PAL:1~25FPS/S
Video bit rate 256KB/384KB/512KB/640KB/768KB/1MB/1.5MB/2MB/2.5MB/3MB/4MB/5MB/6MB/8MB
Audio output 1PCS RCA Port( line level , impedance : 1kΩ)
Audio bit rate 16kpbs
Dual-stream YES
Stream type combine streams/ video stream
Playback resolution 1CH AHD 720P@25fps
4ch D1
4ch 720P IPC
Synchronous palyback D1/CIF/720P/960P
Hard disk
SATA 1*SATA
eSATA No
Capacity each port support max 4TB HDD
External interface
Network interface 1PCS RJ45 10M / 100M adaptive Ethernet port
Serial interface 1PCS RS485
USB interface 2*USB2.0
Alarm in/out NO
General
Power supply DC12V
Comsumption ≤12W
Working temperature -10ºC--+55ºC
Working humidity 10%--90%
Chassis 0.8U
Dmensions(W×D×H) 255*215*45mm
Weight 0.86kg





Product details

  CCTV AHD TVI CVBS IP 4 in 1 Hybrid DVR recorder for security systemCCTV AHD TVI CVBS IP 4 in 1 Hybrid DVR recorder for security systemCCTV AHD TVI CVBS IP 4 in 1 Hybrid DVR recorder for security system









Packaging & Shipping





  Netural package.

shipping by sea, air,DHL, Fedex, UPS. etc.

 AHD/TVI/CVBS/IP Hybrid CCTV DVR recorder for security system

AHD DVR
