Modern Manual Tube Sealing Machine,Soft Tube Sealing Machine
- 30 Unit / Units per Month
- Shanghai/Ningbo Port
- T/T Credit Card
- courrier poly mailer bags cutting and packing Machine
- automatic drink bag juice Bag Sachets Packing Machine
- automatic drink bag juice Bag Sachets Packing Machine
- Plastic Package Stick Packet Three sides Packaging Sealing Machine
- ziplock premade bag filling machine
- Friench Fries Popcorn Packaging peanuts packing machine
Product Details
Condition: | New | Application: | Medical | Place of Origin: | Zhejiang, China |
Brand Name: | Jiangnan | Model Number: | NF-60A |
Product Description
Specifications
Sealing MachineApproved ISO9001
Plumbum tube,Alu tube,plastic tube and laminated tube filling and sealing for pharmacy etc.
Modern Manual Tube Sealing Machine,Soft Tube Sealing Machine
Introduction:
This machine is a high-tech product which successfully developed and designed by adopting advanced technology from abroad and strictly meet GMP requirement. PLC controller and color touch screen are applied and made it possible for programmable control of the machine. It can perform the filling for ointment, cream jellies or viscosity material, sealing or tail folding, batch number embossing (include manufacture date) automatically. It's ideal equipment for plumbum tube, ALU tube, plastic tube and laminated tube filling and sealing for cosmetic, pharmacy, foodstuff and bond industries.
Characteristic:
1. With 12 working stations and matching with manipulator, the machine is able to meet different type of tail folding, sealing requirements of plumbum tube, ALU tube, plastic tube and laminated tubes. It is a multi-purpose machine.
2. Tube feeding, eye marking, tube interior cleaning (optional), material filling, sealing (tail folding), batch number printing, finished products discharging can be performed automatically (the whole procedure).
3. Servo control makes it precise and convenient to adjust the filling amount by touch screen.
4. According to the different length of the tube, height of tube chamber, tube hopper can be adjusted easily by motor. With external reversal feeding system, makes tube charging more convenient and tidy.
5. The mechanical linkage photo sensor precision tolerance is less than 0.2mm. The chromatic aberration scope between tube and eye mark is reduced.
6. Photo-electronic, electric, pneumatic integrative control is applied with the machine. No tube, no filling. It gives an alarm when low pressure occurs. The machine stops automatically if tube error or open the safety door.
7. Three-layer jacket instant heater with inside air heating, it won't damage the pattern outer wall of tube and achieves firm and beautiful sealing effect.
Main technical parameters:
Model | NF-50 | NF-60 | NF80A |
Filling speed | 50pcs/min | 60pcs/min | 80pcs/min |
Suitable tube | plastic tube, laminated tube, ALU tube, plumbum tube | plastic tube, laminated tube, ALU tube, plumbum tube | plastic tube, laminated tube, ALU tube, plumbum tube |
Diameter of tube | φ10-φ35mm | φ10-φ50mm | φ10-φ50mm |
Length of tube | Max. 180mm | Max. 210mm | Max. 220mm |
Filling volume range | 5ml-180ml (Adjustable) | 5ml-240ml (Adjustable) | 5ml-300ml (Adjustable) |
Filling accuracy | ≤±1% | ≤±1% | ≤±1% |
Motor power | 1.1kw | 1.1kw | 1.5kw |
Heat seal power | 3.0kw | 3.0kw | 3.0kw |
Working pressure | 0.55-0.65Mpa | 0.55-0.65Mpa | 0.55-0.65Mpa |
Power supply | 380V/220V | 380V/220V | 380V/220V |
Overall dimension(L*W*H) | 2000*950*1900mm | 2000*950*1900mm | 2000*1220*2400mm |
Weight | 850kg | 850kg | 1300kg |
We Provide You With Sincerely Service, if you interest, please contact us NOW!!!
Tel: 0086-577-65155797, 65155787
Fax: 0086-577-65155862
Website:
/
Website On : http://jiangnanenterprise.en./
Contact Us
- Zhejiang Jiangnan Pharmaceutical Machinery Co., Ltd.
- Contact nameLena Ruan
- Phone86-577-65155797, 65155787
- AddressNo. 833, Xinbu Road, Development Area, Economic Development Zone
