50t Tipperfor Sale

Name: 50t Tipperfor Sale
Brand: Daiyang
SKU: 130927429

US$ 50,000 - 80,000 MOQ: 1 Piece

Key Specifications

Drive Wheel:

6x4

Capacity (Load):

41 - 50t

Horsepower:

351 - 450hp

Shandong Taikai Vehicle Manufacture Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao port

Delivery Detail:

Delivery time depends on order quantity.

Drive Wheel 6x4

Capacity (Load) 41 - 50t

Horsepower 351 - 450hp

Condition New

Transmission Type Manual

Emission Standard Euro 1

Fuel Type Diesel

Gross Vehicle Weight 22000

Place of Origin Shandong, China

Brand Name Daiyang

Model Number TKZ850

Dimensions (L x W x H) (mm) 8427X3000X3910

50t tipper

Model	TKZ850
Drive type	6x4
Curb weight(kg)	22000
Rated load weight(kg)	43000
Dimension(mm)	8427X3000X3910
Max. Speed(km/h)	46
Min. Ground Clearance(mm)	370
Min. Turning radius	10
Max. Grade ability	45
Approach/Departure Angle	33/45
Wheelbase(mm)	3600+1550
Cab	Offset unilateral mine bridge
Engine	YC6M375-20
Type	In-line,6 cylinders, water cooling
Rated power(kw/rpm)	275/2100
Max. (Nm./r/min)	1550/1600
Gear box type	Fast 9JS180
Front axle	13t
Rear axle	25t
Speed radio of rear axle	11.277,11.756
Frame(H x W x T)(mm)	450 X 1000 X(12+10)
Brake system	Double circuit brake, with exhaust brake
Electric system	24V;Minus earth
Air filter	Sand Grade 3
Oil tank capacity(L)	380
Tire	13.0-25;14.0-24
Cargo tank inner dimension(mm)	5600 X 2800 X 1600
Cargo Material	16Mn
Cargo Plate thickness(mm)	Bottom16 Side 10
Max. dip angle	50
Optional parts	Automatic A/C, GPS, Reverse sensor, Automatic spraying system, Whole timing weight system
