1 Channel HDMI over Optical Fiber Transmitter and Receiver Set

Name: 1 Channel HDMI over Optical Fiber Transmitter and Receiver Set
Brand: POWERLINK
Price: USD $10 - 40 / Piece

FOB Price

USD $10 - $40 / Piece

100 Pieces(Min.Order)

Supply Ability 100000 Pair / Pairs per Month
Port CHINA
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:

Guangdong, China

Brand Name:

POWERLINK

Model Number:

PL-HDMI-1CH

Product Description

1 Channel Unidirectional HDMI 3G-SDI/HDMI/VGI over fiber optic video converter transmitter and receiver set 1CH to 64CH cctv fiber video converter fiber optical transmitter and receiver OEM factory

Product Description

Optical Multiplexer is popularly with telecommunication operator and suitable in business for communication operator, government and kinds of entities. It is one of the most transmission equipment in point-point fiber optic network. Typical optical multiplexers are Video & Data & Audio Multiplexers, PDH Multiplexer. Powerlink optical multiplexers are highly manageable, accompanied by a network management system for configuration, service, performance, security, and fault management that enable cost-effective and efficient transport.

HDMI Video Optic Transmission System could transmit uncompressed and high definition HDMI video and audio signal over one 1-core fiber up to 100Km. It’s with Lesser attenuation, wide bandwidth, high anti-interference and safety performance, small size and light weight.
Our products have the incomparable superiorities and characters to in long distance transmission and special environment application.
Over only one 1-core fiber, our products can carry you 1080P video and 190K sampling rate, 8 channels and HI-FI audio signal.
Using our products could save construction cost and difficulty, and ensure high quality signal transmission in multimedia system application

SDI&HDMI&VGI over Fiber Video Converter-Transmitter+ Receiver. Powerlink supply SDI Digital over fiber video converter, 3G-SDI Digital over fiber video converter, HD-SDI over fiber video converter, and SDI-HDMI over fiber video converter. All of our optical/electric interfaces are in accordance with international standards, free of adjustment prior to mounting and applicable in various operating environments. Please feel free to contact us for all your Digital SDI&HDMI&VGI and other video conversion requirements.

HD SDI video signal can be transmitted through one single fiber with non-distortion, high-quality, long-distance transmission. This series of video to fiber converter is with Stable performance, clear picture quality,and high Stability for LED Status Indication on the body of device. The working status of devices can be visually observed. At the same time,the switch value,voltage,working status and other reverse useful signal information can be controlled by data RS485.This makes our devices more flexible when different customers’ request comes.

The FS3020D could transmit HD/SD-SDI as per SMPTE 424M-2006, 292 and 259, with or without embedded audio and data, as well as DVB-ASI over one single mode or multimode fiber. Signals are equalized and re-clocked prior to fiber optic transmission. And HD-SDI Unidirectional Fiber Optic Transmitter should be worked with HD-SDI Unidirectional Fiber Optic Receiver.The price on the website is for Pair.

Features

CRAFT: uncompressed technology
VIDEO SPEC: 1080P 30 Hz
Transmisson Distance:20km
Fiber Type: Single-mode Simplex
2-channel unidirectional HD-SDI and 1-ch reversed RS485/RS232/RS422 data and 1-ch analog audio over one fiber
Range from 19.4Mb/s to 1.485Gb/s
SMPTE 292M (1.485Gb/s) clock recovery
Support all SMPTE 295M standard, 143Mb/s - 360Mb/s
Support SMPTE 305M (SDTi), SMPTE 310M (19.4Mb/s), SMPTE 344M (540Mb/s),M2S and DVB-ASI (270Mb/s) standard
Output wavelength 1310nm,1550nm and 16 types of CWDM (ITU-T G.694.2 compliant)
150m automatic cable equalization, all the 1.485 Gb / s rate below(Belden 1694A)
LED Status Indication to monitor the working conditions and critical parameters
Optional network management system
Support SFP transceiver hot-plugged
Support stand-alone, 1U rack mount and 4U rack mount

Applications

Remote OB Van/Truck Video Feeds
Broadcast Studio Camera Feeds
Long-haul Signal Transport
TV station/video conference
Lecture Hall Projector Connectivity
Medical/Surgical Room Broadcast
Building to ing video conference calling
Small corporate campus video links Product connection diagram

Description for HS-SDI Transmission:

1. Video Interface: High-Definition SDI Video Input (input for signal to be transferred)

2. Fiber-optic video transceiver mark: T: fiber-optic transmitter R: fiber-optic receiver Power Indicator (ON for power-on; OFF for power-off) TX: rns on upon receiving optical signal; turns off when no optical signal is received

3. SDI-DATA: Turns on when SDI signal is input; turns off when there is not. 485/232: Turns on when there is reverse data signal output, or turns off when there is not.

4. Data Interface: Reverse Data Output (for transmission of data sent to optical received) Left: Positive Terminal of Data Output Middle: Negative Terminal of Data Output Right: Earth Terminal (unnecessary for RS485/232 double wires)

Make to Order (Extend information)

Video Interface	Stereo Audio	Fiber Type	Fiber Port	Data Port	Power Supply	Package
1 CH HDMI	1 CH Forward 1 channel reverse 1 channel bidirectional	Single-mode Simplex	FC ST SC LC	1 channel Forward RS485/RS232/RS422 1 channel reverse RS485/RS232/RS422 1 channel bidirectional RS485/RS232/RS422	AC110~260V	stand-alone 1U rack mount

Note: 1.Fiber Port: FC and ST is available,and for SC/LC connector,will provide you a corresponding patch cable for connector conversion for free 2.1 U rack mount:the standard is with 4 slots,Fiberstore will offer you dam-board by free when some slots is empty.

Video
PC input highest resolution	1920×1200@60Hz
HD-DVD input highest resolution	720p/1080i/1080p
Input/output TDMS Signal bandwidth	1.65Gpbs
Input/output TDMS Signal voltage	1.2volts p-p
Input DDC Signal voltage	5volts p-p (TTL)
Fiber Optic
Fiber Choice	Meet IEEE802.3z, 1000BASE_LX Optical connection standards
Wavelength	1310nm
Transmit power	-9.5~-3dBm Average optical power@850nm
Optical receiving sensitivity	-23dBm Average optical power@850nm
Output optical modulation amplitude	180μW
Input optical modulation amplitude	≤15μW
Relative signal strength from	-116 DB/Hz
Return Loss	≤10 dB
Transport bit rate	240M Hz~1.65G Hz
Transmission distance	2km single mode
Environmental conditions
Operating Temperature	-25°C~+70°C
Storage Temperature	-40°C~+80°C
Relative Humidity	0~95%(No condensation)
Power
Power Consumption	5W (max.)
Power supply voltage	9-12VD


Serial TV, BNC Input	Signal standard: SMPTE 292M, 259M, 297M, 305M, 310M, M2S, DVB-ASI, DVB-SSI and Telecom/Datacom
	rate(19.4Mb/s - 1.485Gb/s)
	Input number: 2
	Reflection loss: >15DB
	Equilibrium: 0-150m @1.485Gb/s
	Connector: FC/PC(SC/PC optional)
Optics	Channel: 2
	Type: single-mode (multimode optional)
	Wavelength: 1310nm /1550nm(depends on SFP transceiver)
	Trasmission distance (550m-120Km( depend on SFP transceiver))
	Reflection loss: > 15dB
	Dithering: < 0.2UI
	Connector:LC/ FC/PC (SC/PC optional)
Serial TV, BNC output (EO/OE)	Channel: 2 (2 channel optional)
	Signal level: 800mV nominal
	Rise/fall time: 200ps indication
	Overshoot: < 10% amplitude
	Reflection loss: >15dB
	Dithering: < 0.2UI
	Connector: 75Ω BNC
Analog audio	Input/ output impedance: 600Ωequilibrium
	Input/output interface: XLR
	Max. input/output level: +15 dBu
	Frequency Response: 20Hz-20KHz,±0.1dB
	SNR: > 85dB(A weighted)
	THD+N: < 0.01%@1KHz
	Crosstalk: < -90dB
Data	Channel: 1
	Data format: RS-485/422/RS232 (full/half duplex) and support NRZ, RZI and Manchester
	Data rate: DC to 100 Kb/s
	Mode: Full/half duplex
	Connector: wire connecting terminal
Power and environmental indication	Operating temperature: -30°C~+50°C
	Pressure: 1A@12VDC
	Power: 12 W
	EMI/RFI: meet FCC Part 15 Class A, EU EMC standard
	Average time trouble-free: >100000 hours
SDI video format supports
	625/25PAL;525/29.97NTSC;525/23.98NTSC; 720p50; 720p59.94; 1080P23.98/24/30/50/60; 1080i 23/24/30/50/59.94;

Packaging & Shipping

Packaging : bags&caron box
Shipping: International Express: Fedex, DHL, UPS, TNT and EMS.If you have another preferred carrier, please notify us in advance.
