Home > Electrical & Electronics > Switch > Wall Switch > SMART WIRELESS REMOTE SWITCH,GLASS PANEL TOUCH AND REMOTE SWITCH
SMART WIRELESS REMOTE SWITCH,GLASS PANEL TOUCH AND REMOTE SWITCH
US$ 25 - 45
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
CATRY
Model Number:
CA-AN03(FJ0166)
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
HOME AUTOMATION SWITCH,SMART SWITCH WITH GLASS PANELUS$ 25 - 45MOQ: 100 Pieces -
Touch & Remote Light Switch ,Home Automation SwitchUS$ 25 - 45MOQ: 100 Pieces
-
Glass Panel Touch and Remote SwitchUS$ 26 - 45MOQ: 100 Pieces
-
SMART SWITCH,SMART GLASS PANEL SWITCHUS$ 22.5 - 47MOQ: 100 Pieces
-
WIRELESS REMOTE CONTROL AND TOUCH SWITCHUS$ 22.5 - 47MOQ: 100 Pieces
Place of Origin
Guangdong, China
Brand Name
CATRY
Model Number
CA-AN03(FJ0166)
Size
86*86mm
Max. Current
10
Max. Voltage
250
Mechanical Life
1000000TIMES
The light switches can, if needed, be controlled by an optional master remote control. This gives the user the power to turn on/off any light switch in the home, or set scenes - patterns of light - in different rooms, without the need for expensive controllers or senders.All models in the Touch and Remote full glass range measure 86mm x 86mm, have a stylish glass surround with chrome trim, and come with a 2 year warranty. CATRY electrical switches give the user the power to control their lighting the way they want, using the advanced features or simple controls.
They are a retrofit, therefore use existing wiring and are less expensive, quick and easy to install; unlike many other home automation products developed for installation primarily in new-builds.
FULL FEATURES:
•Touch or remote controlled (turns off/on individually or both together)
•Remote control can be used through walls (RF)
•Retrofit solution (Uses existing wiring)
•Glass surround with chrome trim
•3 Gang (Controls 3 Lights)
•Microlite touch panel (Patented Technology)
•Blue glow for easy night use
•Ideal for all living areas
•Concealed fixing screws
•Quick & easy installation
•Modern design light switch
•Easy Clean
•Can be used with optional master remote control
TECHNICAL SPECIFICATION:
•Rated Voltage: 220~240V AC, Frequency: 50/60Hz
•Capability allowance: -15%~+10% 187~264V
•Operating Power: 1 Gang One-way Applicable Load :
A: Resistive load (incandescent lamp),
B: Condensive load(electronic fluorescent lamp/energy saving lamp)
C: Inductive load(transformer driver load, motor)10-200W;
2 Gangs One-way Applicable Load.
A: Resistive load 7~1500W,(each circuit<750W)
B: Condensive load and inductive load 10~150W
3 Gangs One-way Applicable Load
A: Resistive load 7-1800W,(each circuit≤600W)B: Condensive load and inductive load 10-150W, is not suitable
for inductive fluorescent lamp.
•Working Environment: Working Temperature: 0oC~40oC Relative Humidity: 10% - 93%
•Energy Consumption: <0.02W
•Measurement: 86x86mm
•life: 100,000 times at least (relay useful life) Remote usage distance >20M
•Power: < 0.1mW
•CE & RoHS Certified
What you get inside box:
• CATRY Light Switch
•Mini Remote Control
•Instruction booklet
•2 screws
•2 year Warranty
