CPVC Scheduel 80 PIPE 20"

FOB Price

US$ 0.2 - 10 / Meter

1000 Meters(Min. Order)

Port Shanghai

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China	Brand Name	DFP
Model Number	SCH80 PIPE	Material	Other, CPVC
Specification	1/2"~24"	Length	1~6M
Thickness	According to the ASTM D-1785 Standard	Standard	SCH80 (ASTM D-1785), SCH40/SCH80

Product Description

SHIE YU Professional in UPVC, CPVC, HDPE, PPH, PVDF PIPE&FITTINGS

SHIE YU Milestones

-1973, Shieyu Group is established in Taichung

-1994, first company in Taiwan gained NSF listing

-1997, obtained ISO9001

-1999, established Kaohsiung facility to produce fittings and pipes

-2002, established manufacturing facility in China

-2008, China facility obtained NSF listing for CPVC CTS fittings.

-2012, Group annual turnover rate is 100 million USD.

-2013.05, Celebrated 40thanniverysary

-2013.08, China facility obtained NSF listing for UPVC SCH80 pipes and fittings

-2013.12, Set up second facility in Kunshan specializing in PPH/PVDF/ECTFE/HDPE products under the brand ASIAN VALVE.

Company information

1.We have own factoty for over 40 years with good quality and Service.

2.Good Quality: Implement NSF and ISO quality system on all products.

3.Good reputation in Southeast Asian,Middle east, South America market.

4.We have complete product ranges.

Standards: DIN, Sch80, Sch40, JIS, BS, or other assigned standards

5.Flexible lead time.

Product Name: CPVC SCH80 PIPE

Description:

1.Material:	CPVC
2.Size Available:	1/2"~24"
3.Standard:	SCH80(ASTM D-1785)
4.Color:	Gray
5.Brand:	DFP
6.Connection:	SCOKET
7.MOQ:	1000m
8.Prodction Capatity	20000m per Month
9.Product Tests:	100% tested
10.Certification Available:	ISO,NSF,CNAS

Pipe Dimension:

Nom. Size(Inch)	Pipe O.D.	Tolerance	Min.Wall Thickness
	Inch(mm)	Inch(mm)	Inch(mm) Inch(mm)
1/8"	0.405(10.29)	±0.004(0.10)	0.095(2.41)
1/4"	0.54(13.72)	±0.004(0.10)	0.119(3.02)
3/8"	0.675(1.15)	±0.004(0.10)	0.126(3.2)
1/2"	0.84(21.34)	±0.004(0.10)	0.147(3.73)
3/4"	1.04(26.67)	±0.004(0.10)	0.154(3.91)
1"	1.315(33.4)	±0.005(0.13)	0.179(4.55)
1-1/4"	1.66(42.16)	±0.005(0.13)	0.191(4.85)
1-1/2"	1.9(48.26)	±0.006(0.15)	0.2(5.08)
2"	2.375(60.33)	±0.006(0.15)	0.218(5.54)
2-1/2"	2.875(73.03)	±0.007(0.18)	0.276(7.01)
3"	3.5(88.9)	±0.008(0.20)	0.30(7.62)
4"	4.5(114.3)	±0.009(0.23)	0.337(8.56)
5"	5.563(141.3)	±0.010(0.25)	0.375(9.53)
6"	6.625(168.28)	±0.011(0.28)	0.432(10.97)
8"	8.625(219.08)	±0.015(0.38)	0.500(12.7)
10"	10.75(273.05)	±0.015(0.38)	0.593(15.06)
12"	12.75(323.85)	±0.015(0.38)	0.687(17.45)
14"	14.00(355.6)	±0.015(0.38)	0.750(19.05)
16"	16.00(406.4)	±0.019(0.48)	0.843(21.41)
18"	18.00(457.2)	±0.019(0.48)	0.937(23.8)
20"	20.00(508)	±0.023(0.58)	1.031(26.19)
24"	24.00(609.6)	±0.031(0.79)	1.218(30.94)

CPVC Physical Property:

PROPERTIES	UNIT	INDEX	TEST METHOD
Specific Gravity	g/cm³	1.5-1.6	ISO 1183
Vicat Softening Temperture	°c	105	ISO 306
Tensile Strength	Mpa	55	ISO 527-2
Impact Strength	KJ/M²	11	ISO 179
Tensile Modulus	Mpa	2700	ISO 527-2

Product Picture:

Product Advantage:

1.CPVC(Chlorinated Polyvinyl Chloride)---withstand low to high levels of chemical corrosions such as most acids, alkalis, and salt solutions and great thermal resistance

2.Non-toxic, ageless,compatible in PH solutions, abrasion-resistant, nondeforming,soomth inner surface,noscaling,less dirt,thermal retention,cold weld,hassle-free installation

3.Longer performance life,easy and quick maintenance

4Easy handling, lower installation costs

ISO Certificate:

NSF Certificate:
