Name: 30Mpa Strain Gage Force Sensor
Brand: CZS
SKU: 130871413
Availability: InStock

ALL CATEGORIES

30Mpa Strain Gage Force Sensor

Send Inquiry to This Supplier

Mrs. Alice xie

sales manager

Changsha Naisi Electronic Equipment Co., Ltd.

Changsha, Hunan, China

Message

0/5000

* Email

PARAMETERS:
Capacity Range	0-10-100MPa
Comprehensive Precision	0.1%FS , 0.2%FS, 0.3%FS, 0.5%FS, 1.0%FS
Output Signal	4~20mA; 0~5V; 1~5V; 0~10V
Use Temp Range	-10℃~+80℃
Electric Connectio	4-core plug or take-up nut
Excitation Voltage	9~36V, if output =4~20mA or 0~5V or1~5V; 15~36V, if outpur= 0~10V
Stability	0.1%F.S/year
Burden Resistance	Current output: ≤800Ω,Voltage output :≥50KΩ
Insulation Resistance	≥2000MΩ,100VDC
Effection of Vibration	On 20HZ-1KHZ of mechanical shake, output ≤ 0.1%F.S
Defend Grade	IP68

PARAMETERS:
Capacity Range	0-10-100MPa
Comprehensive Precision	0.1%FS , 0.2%FS, 0.3%FS, 0.5%FS, 1.0%FS
Output Signal	4~20mA; 0~5V; 1~5V; 0~10V
Use Temp Range	-10℃~+80℃
Electric Connectio	4-core plug or take-up nut
Excitation Voltage	9~36V, if output =4~20mA or 0~5V or1~5V; 15~36V, if outpur= 0~10V
Stability	0.1%F.S/year
Burden Resistance	Current output: ≤800Ω,Voltage output :≥50KΩ
Insulation Resistance	≥2000MΩ,100VDC
Effection of Vibration	On 20HZ-1KHZ of mechanical shake, output ≤ 0.1%F.S
Defend Grade	IP68

30Mpa Strain Gage Force Sensor

Product Details
