SM40 Silo Forming and Seaming Machine

Yingkou Professional Roll Forming Machine Co., Ltd.
SM40 Silo Forming and Seaming Machine thumbnail-1
SM40 Silo Forming and Seaming Machine photo-1
US$ 10 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Liaoning, China
Brand Name:
PRO
Model Number:
SM30/40
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Liaoning, China
Brand Name PRO
Model Number SM30/40
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.Electrical equipment power: 27kw
2.Raw material width: 495mm
3.Finished width: 350---370mm
4.Material thickness:2-4mm



    SM40 silo forming and seaming machine



SM40 silo forming and seaming machineSM40 silo forming and seaming machine




Product Description





Main technical parameter:

(1)  Required thickness of raw material:

A,Galvanized sheet——2---4mm

B,Dark steel sheet——2---4mm

C,Chromated nickel steel sheet——2---3mm

D,Plastic coatings steel sheet——2---4mm

(2)Raw material width: 495mm

(3)Finished width: 350---370mm

(4)Diameter: 4m---30m



The diagram of the suturing part:

Bending 5 times to make the silo is tighter.









  • Decoiler





Size: 1700x1500x900 (mm)

Weight: About 300kg

Application: moving steel coils that put on the decoiler, making steel coils can into forming machine successfully.







  • Joint frame

SM40 silo forming and seaming machine



Size: 1600x1600x1500 (mm)

Weight: About 100kg/pcs

Application: Joining the load bearing support, locking the required diameter of soil, making the load bearing support stable working.





  • Load bearing support:





Size: 1800x400x400 (mm)

Weight: About 50kg/pcs

Application: Given the right diameter of silo, support the spiral rising silo.
