ATTEN AT8586 2 in 1 Advanced Hot Air Soldering Station,750W SMD Rework Station

Specifications

ATTEN AT8586 2 in 1 Advanced Hot Air Soldering Station,750W SMD Rework Station



ATTEN AT8586 2 in 1 Advanced Hot Air Soldering Station,750W SMD Rework Station





• Hot air station and soldering station set(the two of them can work separately without mutural interference).
• Digital LED temperature display, so that the operation more convenient and accurate.
• Self-examine and error check, with screen remindings to guide people to repair.
• Adopts Closed-loop control sensors for temperature accuracy and stability.
• Ideal for safe demolition solder QFP, PLCC, SOP, BGA and other chips and components which are temperature-sensitive.
• Intelligent cooling system, after the shutdown delay completion of the work of air, air temperature lower than 100 automatically cut off power supply.
• Use of imported air pump for low vibration, noise-free design and maintain a quiet working environment.
• Static elimination design, prevent PCB board damage due to static or electric leakage.

Features:
* Machine from the hot air rework station and integrated welding units constitute a multi-functional integrated maintenance system Rework;
* The core of the chip micro-computer chip machine centralized control to ensure the hot air station and soldering station, temperature accuracy and stability rather than a simple combination of two devices;
* Clear digital display the current temperature and working conditions;
* Numerical keys on the temperature of hot air soldering station, temperature and continuous adjustments to adapt to different workplace needs;
* Visual fault indicator.



Specifications:

Machine:
Rated Voltage: AC 220V ± 10% 50Hz
Total Power: 750W (Max)
Work environment :0-40
Relative humidity: "80%
Storage Temperature: -20 -80



Hot air rework station
Operating voltage: AC 220V ± 10% 50Hz
Output Power: 700W
Temperature range: 100 -500
Temperature Stability: ± 5
Gas flow: 120L/min (max)



Welding table
Operating voltage: AC 26V 50Hz
Output Power: 50W
Temperature range: 200 -480
Temperature Stability: ± 2 (static)
Tip to ground resistance: <2Ω
Tip-to-ground voltage: 3mV
