Handheld Infrared Thermal Imager Infrared IR thermal imaging Camera with resolution 160*120
Handheld Infrared Thermal Imager Infrared IR thermal imaging Camera with resolution 160*120
MinIR series thermal cameras are the third generation of upright style. Light weight with an ergonomic compact design for one handed operation, MinIR is the leading entry level thermal camera in the market. The advanced UFPA detector used in MinIR has a low 80mk thermal sensitivity which generates clear and accurate thermal images. MinIR’s multi functional design meets the requirements for various applications and industries.
UFPA Detectors
High quality infrared detector
50Hz Frame Rate
Real time motion capture
Intuitive and fast temperature measurement
MinIR series has 3 temperature measurement modes. Centre point temperature measurement, maximum temperature capture and minimum temperature capture.
Ten languages
English/French/German/Italian/Spanish/Portuguese/Chinese/Japanese/Russian/Korean
Image performance:
FOV/Min. focus distance |
20°x15°/0.1m |
Spatial resolution |
2.2 mrad |
Thermal sensitivity |
≤0.08°C@30°C |
Detetor type |
UFPA(Uncooled focal plane array) |
Detetor resolution |
160 x120 |
Spectral range |
8-14um |
Focus |
Manual |
Image presentation:
Image mode |
IR |
Video output frequency |
NTSC (60Hz) or PAL (50Hz) full dynamic output |
LCD Display |
3” TFT screen |
Weight |
less than 500g |
