Stainless Steel Color Video Camera Pipeline Inspection System With Durable Carry Case Pipe Inspection Camera

Stainless Steel Color Video Camera Pipeline Inspection System With Durable Carry Case Pipe Inspection Camera thumbnail-1
Stainless Steel Color Video Camera Pipeline Inspection System With Durable Carry Case Pipe Inspection Camera photo-1
US$ 580 - 680 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Graigar
Model Number:
710DM
Contact Supplier Request Quote Chat Now
Shenzhen Graigar Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
china
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Graigar
Model Number 710DM

Specifications

Pipeline Inspection Stainless Steel Color Video Camera Pipeline Inspection System With Durable Carry Case Pipe Inspection Camera

Stainless Steel Color Video Camera Pipeline Inspection System With Durable Carry Case Pipe Inspection Camera



MODEL NO.710DM



SUPPORT CUSTOM-MADE, accessaries changeable.

Product features:

1 Camera:

23mm diameter size.

12 pcs Leds

Waterproof sapphire lens.

Stainless housing.

2 Monitor:

7 inch big& cool monitor.

High-definition:720 X 576

SD card icon and SD capacity osd.

3 DVR:

Video&audio record.

Leds of camera adjustable.

Power light flash before power off in case of video lost.

4 Battery work time: ≥260minutes.

5 AL case: portable

6 Skids: support the camera in the middle of pipe.

Packing list:

1 23mm camera

2 20-80m cable

3 7 inch Monitor

4 DVR

5 Li-on Battery

6 Charger

7 Skids

8 AL Case

Specification:

Camera
1 Camera size: Φ23 X 120mm    2 Camara power supply: DC 3.3V
3 Stainless steel shell /sapphir glass 4 Camera work current: 100MA
5 Sensor size: 1/4 inch 6 Waterproof: IP68
7 Total Pixels: PAL: 720X576 NTSC: 720X480 8 Camera light: 12PCS white LEDS, illumination adjustable
9 View angle: 120° 10 Work temperature: -10°C-50°C
DVR
1 DVR Total Pixels: 720X576 (D1) 2 Movie format: AVI
3 DVR work current: 200MA DVR power supply: 12V 4 Microphone audio record
5 Storage medium: SD card  (max 32G) 6 Stereo earphone output
7 Dagital clock and dagital calendar 8 USB keyboard input
9 Picture snap and movie record 10 Max edit page: 4 pages
Monitor
1 Monitor size: 7inch TFT color monitor 2 Up,down,left,right adjustable
3 Monitor Total Pixels: 1440 X 234 4 16:9&4:3 model
5 Monitor power supply: DC 12V 6 Sunshade include
7 Osd language: English 8 Waterproof connector
Cable wheel
1 Cable size: Φ320XH110mm 2 Fiberglass diameter: 4.8mm
3 Wire material: fiberglass rod 4 Fiberglass color: yellow/blue
5 Cable length: 20-80 changeable 6 Wheel material:stainless steel
Microphone
1 Frequency respose: 20~20KHz 2 Line Length: 1m
Li-on battery
1 Charge time: 5hours ; Work time: ≥260minutes 2 12V 4000MAH battery
Skid
Φ40&80mm
Charger
1 input: AC100-240V~50/60Hz 2 Output: DC 12V/1000MA
3 DC plug diameter :2.1mm
AL Case ABS Case
1 Material:fire board+Aluminum alloy 1 Material:engineering plastic
2 Size: L480XW415XH200mm  2 Size: L520XW435XH200mm
3 Color:black  3 Color: orange/green/black



Stainless Steel Color Video Camera Pipeline Inspection System With Durable Carry Case Pipe Inspection Camera
